Cloud Connection Plug, 5mm - 3-Way

Price Each £2.77 (£3.32 Including VAT at 20%)

REF: JP98511

Quantity:

Cloud Connection Plug, 5mm - 3-Way

The Cloud Connection Plug used for all Cloud equipment which uses pluggable terminal blocks with screw terminals for interconnections between audio inputs, remote volume control panels and speaker outputs. It is a professional rising clamp terminal with 2 to 20 pole solid block and is moulded in green flame retardant PA. It has 0.2 to 1mm² (30 to 16AWG) solid and stranded cable.

Click Here for Printer Friendly Version

Cloud Connection Plug Features

- >=2.5kV Dielectric strength
- 4kV Impulse withstand voltage
- 0.5Nm Torque
- 1.4mm Recommended PCB hole size

Cloud Connection Plug Specifications

- Pitch Spacing: 5mm
- Wire Size (AWG): 30AWG to 12AWG
- Conductor Area CSA: 2.5mm²
- Wire Connection Method: Screw
- Rated Current: 12A
- Rated Voltage: 320V
