Acme CA M26 DMX Merger/Splitter Controller

Name: Acme CA M26 DMX Merger/Splitter Controller
Brand: Acme
SKU: 0721405345243
Price: 205.42 GBP
Availability: InStock

Price Each £171.18 (£205.42 Including VAT at 20%)

REF: JP37096

Quantity:

Acme CA M26 DMX Merger/Splitter, This combined DMX merger/splitter and amplifier has 2 DMX inputs and 6 DMX outputs, each equipped with both 3-Pin and 5-Pin XLR connectors for versatility. The splitter function distributes the DMX signal(s) from the input(s) over 6 identical outputs which are 100% isolated from each other. DMX data packet refresh rate adjustment. DMX merging is offered in several ways: (1) HTP: The highest value of 2 identical channels from 2 DMX signals takes priority. (2) Backup: When the DMX signal on input A fails, the DMX signal in input B takes over immediately. (3) Merger: DMX signals from two different controllers can be combined and sent down a single cable, selectable start address for the second controller.

Click Here for Printer Friendly Version

CA M26 DMX Merger/Splitter Features

- Split and merge DMX signals
- 2 DMX inputs and 6 DMX outputs
- 3-Pin and 5-Pin XLR inputs/outputs
- DMX refresh rate: 23ms (44Hz) to 45ms (22Hz)
- 100% electrical isolation between all inputs/outputs
- 1U, 19" rack mountable

CA M26 DMX Merger/Splitter Specifications

- Power supply: 240V, 50Hz
- Dimensions: 44 x 482 x 150mm
- Weight: 2.9kg

Further Product Information Below

Acme CA M26 Manual (PDF)

Acme CA M26 CE Certification (PDF)
