B&C ME90 1.4-Inch Horn Flare - 80 x 60 Degree Dispersion

B&C ME90 1.4-Inch Horn Flare Features

- 1.4-inch throat entry
- 80° x 60° nominal coverage
- Constant Directivity
- Excellent loading down to 900 Hz

B&C ME90 1.4-Inch Horn Flare Specifications

- Throat Diameter: 36 mm (1.4 inch)
- Nominal Coverage:
  - Horizontal: 80 °
  - Vertical: 60 °
- Cutoff Frequency: 0.9 kHz
- Material: Cast Aluminium
- Design: Constant Directivity

Physical:
- Dimensions (W x H x D): 270 x 270 x 138 mm (10.6 x 10.6 x 5.4 inches)
- Baffle Cutout Dimension (W x H): 225 x 225 mm (8.86 x 8.86 inches)
- Driver Mounting: 4x 6.5 mm (0.255 inch) holes 90° on 102 mm (4 inch) diameter
- Net Weight: 1.45 kg (3.19 lb)

Further Product Information Below

B & C ME90 Data Sheet (PDF)

B & C ME90 Technical Drawing (PDF)
