B&C ME60 2-Inch Horn Flare - 60 x 40 Degree Dispersion

B&C ME60 2-Inch Horn Flare Features

- 2-inch throat entry
- 60° x 40° nominal coverage
- Constant Directivity
- Excellent loading down to 800 Hz

B&C ME60 2-Inch Horn Flare Specifications

- Throat Diameter: 50 mm (2.0 inch)
- Nominal Coverage:
  - Horizontal: 60 °
  - Vertical: 40 °
- Cutoff Frequency: 0.8 kHz
- Material: Cast Aluminium

Physical:
- Dimensions (W x H x D): 270 x 237 x 202 mm (10.6 x 9.3 x 7.9 inches)
- Baffle Cutout Dimension (W x H): 232 x 207 mm (9.1 x 8.1 inches)
- Driver Mounting: 4x 6.5 mm (0.255 inch) holes 90° on 102 mm (4 inch) diameter
- Air Volume Occupied by Driver: 0.45 dm³ (0.02 ft³)
- Net Weight: 1.69 kg (3.73 lb)

Further Product Information Below

B & C ME60 Data Sheet (PDF)

B & C ME60 Technical Drawing (PDF)
