B&C DE910TN 1.3-Inch Compression Driver - 110W RMS, 16 Ohm

Name: B&C DE910TN 1.3-Inch Compression Driver - 110W RMS, 16 Ohm
Brand: B&C
SKU: JP61393
Price: 317.34 GBP
Availability: InStock

Price Each £264.45 (£317.34 Including VAT at 20%)

REF: JP61393

Quantity:

B&C DE910TN 1.3-Inch Compression Driver - 110W RMS, 16 Ohm

The B&C DE910TN boasts legendary B&C technology made with their famously critical quality control, allowing loudspeaker designs with appropriately scaled performance.

Replacement Diaphragm: JP61369 (B&C MMD3BTN)

Click Here for Printer Friendly Version

B&C DE910TN 1.3-Inch Compression Driver Features

- 220 W continuous program power capacity
- 1.3-inch horn throat diameter
- 75 mm (3 inch) aluminium voice coil
- Titanium diaphragm
- 500 - 18000 Hz response
- 108.5 dB sensitivity
- Neodymium magnet assembly with shorting copper cap

B&C DE910TN 1.3-Inch Compression Driver Specifications

- Throat Diameter: 33 mm (1.3 inches)
- Nominal Impedance: 16 Ω
- Minimum Impedance: 10.5 Ω
- Nominal Power Handling: 110 W
- Continuous Power Handling: 220 W
- Sensitivity (1W/1m): 109.0 dB
- Frequency Range: 0.5 - 18 kHz
- Recommended Crossover: 1.2 kHz
- Voice coil Diameter: 75 mm (3.0 inches)
- Winding Material: Aluminium
- Inductance: 0.14 mH
- Diaphragm Material: Titanium
- Flux Density: 2.05 T
- Magnet Material: Neodymium Ring

Physical:
- Mounting:
- Four M6 holes 90° on 102 mm (4 inch) diameter
- Four M6 Mounting Studs with bolts and washers included
- Overall diameter: 131 mm (5.15 inches)
- Depth: 52 mm (2.0 inches)
- Net weight: 2.4 kg

Further Product Information Below

B & C DE910TN (16 Ohm) Data Sheet (PDF)

B & C DE910TN Technical Drawing (PDF)
