B&C DE680TN 1.4-Inch Compression Driver - 80W RMS, 8 Ohm

Name: B&C DE680TN 1.4-Inch Compression Driver - 80W RMS, 8 Ohm
Brand: B&C
SKU: JP61403
Price: 182.47 GBP
Availability: InStock

Price Each £152.06 (£182.47 Including VAT at 20%)

REF: JP61403

Quantity:

B&C DE680TN 1.4-Inch Compression Driver - 80W RMS, 16 Ohm

The B&C DE680TN is the latest version of B&C's premium 65 mm (2.5 inch) voice coil, neodymium high frequency driver. The diaphragm in this model has been completely redesigned to incorporate a bent edge voice coil former, as well as new dome and surround geometry. These modifications combine to better control diaphragm displacement and deformations, resulting in lower distortion and a smoother higher frequency response above 10kHz.

Replacement Diaphragm: JP101971 (B&C MMD25BTN)

Click Here for Printer Friendly Version

B&C DE680TN 1.4-Inch Compression Driver Features

- 160 W continuous program power capacity
- 1.4-inch horn throat diameter
- 65 mm (2.5 inch) aluminium voice coil
- Titanium diaphragm
- 1000 - 18000 Hz response
- 108 dB sensitivity
- Neodymium magnet assembly with shorting copper cap

B&C DE680TN 1.4-Inch Compression Driver Specifications

- Throat Diameter: 36 mm (1.4 inches)
- Nominal Impedance: 8 Ω
- Minimum Impedance: 7.7 Ω
- Nominal Power Handling: 80 W
- Continuous Power Handling: 160 W
- Sensitivity (1W/1m): 108.0 dB
- Frequency Range: 1.0 - 18 kHz
- Recommended Crossover: 1.2 kHz
- Voice coil Diameter: 65 mm (2.5 inches)
- Winding Material: Aluminium
- Inductance: 0.15 mH
- Diaphragm Material: Titanium
- Flux Density: 1.8 T
- Magnet Material: Neodymium Ring

Physical:
- Mounting:
- Four M6 holes 90° on 102 mm (4 inch) diameter
- Four M6 Mounting Studs with bolts and washers included
- Overall diameter: 115 mm (4.5 inches)
- Depth: 51 mm (2.0 inches)
- Net weight: 1.75 kg

Further Product Information Below

B & C DE680TN (8 Ohm) Data Sheet (PDF)

B & C DE680TN Technical Drawing (PDF)
