B&C DE550TN 1-Inch Compression Driver - 70W RMS, 16 Ohm

Price Each £124.91 (£149.89 Including VAT at 20%)

REF: JP108493

Quantity:

B&C DE550TN 1-Inch Compression Driver - 70W RMS, 16 Ohm

The B&C DE550TN 1-Inch Compression Driver boasts legendary B&C technology made with their famously critical quality control, allowing loudspeaker designs with appropriately scaled performance.

Click Here for Printer Friendly Version

B&C DE550TN 1-Inch Compression Driver Features

- 140 W continuous program power capacity
- 1-inch horn throat diameter
- 51 mm (2 in) aluminium voice coil
- Titanium diaphragm
- 1000 - 17000 Hz response
- 108 dB sensitivity

B&C DE550TN 1-Inch Compression Driver Specifications

- Throat Diameter: 25 mm (1.0 in)
- Nominal Impedance: 16 Ω
- Minimum Impedance: 13.5 Ω
- Nominal Power Handling: 70 W
- Continuous power handling: 140 W
- Sensitivity (1W/1m): 109.0 dB
- Frequency Range: 1000 - 17000 Hz
- Recommended Crossover: 1.2 kHz
- Voice Coil Diameter: 51 mm (2.0 in)
- Winding Material: Aluminium
- Inductance: 0.14 mH
- Diaphragm Material: Titanium
- Flux Density: 2.0 T
- Magnet Material: Neodymium Ring

Physical:
- Mounting:
- Two M6 holes 180° on 76 mm (3 in) diameter
- 2x M6 Mounting Studs with bolts and washers included
- Overall Diameter: 92 mm (3.62 in)
- Depth: 49 mm (1.93 in)
- Net Weight: 1.17 kg (2.58 lb)

Further Product Information Below

B & C DE550TN (16 Ohm) Data Sheet (PDF)

B & C DE550TN Technical Drawing (PDF)
