B&C DE52 1.4-Inch Compression Driver - 70W RMS, 8 Ohm

Name: B&C DE52 1.4-Inch Compression Driver - 70W RMS, 8 Ohm
Brand: B&C
SKU: JP61394
Price: 110.21 GBP
Availability: InStock

Price Each £91.84 (£110.21 Including VAT at 20%)

REF: JP61394

Quantity:

B&C DE52 1.4-Inch Compression Driver - 70W RMS, 8 Ohm

The B&C DE52 boasts legendary B&C technology made with their famously critical quality control, allowing loudspeaker designs with appropriately scaled performance.

Click Here for Printer Friendly Version

B&C DE52 1-Inch Compression Driver Features

- 140 W continuous program power capacity
- 1.4-incg horn throat diameter
- 51 mm (2 inch) aluminium voice coil
- HT Polymer diaphragm
- 1000 - 17000 Hz response
- 108 dB sensitivity

B&C DE52 1-Inch Compression Driver Specifications

- Throat Diameter: 25 mm (1 inches)
- Nominal Impedance: 8 Ω
- Minimum Impedance: 8.2 Ω
- Nominal Power Handling: 70 W
- Continuous Power Handling: 140 W
- Sensitivity (1W/1m): 108.0 dB
- Frequency Range: 1.0 - 17 kHz
- Recommended Crossover: 1.0 kHz
- Voice coil Diameter: 51 mm (2.0 inches)
- Winding Material: Aluminium
- Inductance: 0.14 mH
- Diaphragm Material: HT Polymer
- Flux Density: 1.8 T
- Magnet Material: Ferrite

Physical:
- Mounting:
- Four M6 holes 180° on 76 mm (3 inch) diameter
- Four M6 Mounting Studs with bolts and washers included
- Overall diameter: 134 mm (5.28 inches)
- Depth: 60 mm (2.36 inches)
- Net weight: 2.8 kg

Further Product Information Below

B & C DE52 (8 Ohm) Data Sheet (PDF)

B & C DE52 Technical Drawing (PDF)
