B&C DE500 1-Inch Compression Driver - 50W RMS, 8 Ohm, Spade Terminals

Price Each £126.02 (£151.22 Including VAT at 20%)

REF: JP61024

Quantity:

B&C DE500 1-Inch Compression Driver - 50W RMS, 8 Ohm, Spade Terminals

The B&C DE500 boasts legendary B&C technology made with their famously critical quality control, allowing loudspeaker designs with appropriately scaled performance.

Replacement Diaphragm: JP61283 (B&C MMD5008)

Click Here for Printer Friendly Version

B&C DE500 1-Inch Compression Driver Features

- 100 W continuous program power capacity
- 1-inch horn throat diameter
- 44 mm (1.7 inch) aluminium voice coil
- Titanium diaphragm
- 1000 - 18000 Hz response
- 107 dB sensitivity
- Optimized Neodymium magnet assembly
- Shorting copper cap for extended HF response

B&C DE500 1-Inch Compression Driver Specifications

- Throat Diameter: 25 mm (1 inches)
- Nominal Impedance: 8 Ω
- Minimum Impedance: 7.6 Ω
- Nominal Power Handling: 50 W
- Continuous Power Handling: 100 W
- Sensitivity (1W/1m): 107.0 dB
- Frequency Range: 1.0 - 18 kHz
- Recommended Crossover: 1.5 kHz
- Voice coil Diameter: 44 mm (1.7 inches)
- Winding Material: Aluminium
- Inductance: 0.11 mH
- Diaphragm Material: Titanium
- Flux Density: 1.9 T
- Magnet Material: Neodymium Ring

Physical:
- Mounting:
  - Two M6 holes 180° on 76 mm (3.0 inch) diameter
  - Three M6 holes 120° on 57 mm (2.2 in) diameter
  - Three M6 Mounting Studs with bolts and washers included
- Overall diameter: 102 mm (4.0 inches)
- Depth: 51 mm (2.0 inches)
- Net weight: 1.43 kg

Further Product Information Below

B & C DE500 (8 Ohm) Data Sheet (PDF)

B & C DE500 Technical Drawing (PDF)
