B&C DE36 1-Inch Compression Driver - 35W RMS, 8 Ohm

Name: B&C DE36 1-Inch Compression Driver - 35W RMS, 8 Ohm
Brand: B&C
SKU: JP101915
Price: 62.09 GBP
Availability: InStock

Price Each £51.74 (£62.09 Including VAT at 20%)

REF: JP101915

Quantity:

B&C DE36 1-Inch Compression Driver - 35W RMS, 8 Ohm

The B&C DE36 features a ketone polymer diaphragm with a ferrite magnet motor. Extensive FEA modeling and physical testing over the last several years has culminated in these 1.5 inch (38 mm) coil ring drivers with outstanding sensitivity, high frequency extension, and compactness. A practical recommended crossover point of 1.8 kHz and sensitivity of 108 dB in the DE36 allows for a wide range of applications, including compact two way boxes and line arrays.

Click Here for Printer Friendly Version

B&C DE36 1-Inch Compression Driver Features

- 70 W continuous program power capacity
- 1-inch horn throat diameter
- 38 mm (1.5 inch) aluminum voice coil
- 1200 - 20000 Hz response
- 107.5 dB sensitivity
- Annular HT polymer diaphragm

B&C DE36 1-Inch Compression Driver Specifications

- Throat Diameter: 25 mm (1 inch)
- Nominal Impedance: 8 Ω
- Minimum Impedance: 7.2 Ω
- Nominal Power Handling: 35 W
- Continuous Power Handling: 70 W
- Sensitivity (1W/1m): 107.5 dB
- Frequency Range: 1.2 - 20 kHz
- Recommended Crossover: 1.8 kHz
- Voice coil Diameter: 38 mm (1.5 inches)
- Winding Material: Aluminium
- Inductance: 0.12 mH
- Diaphragm Material: HT Polymer
- Flux Density: 1.6 T
- Magnet Material: Ferrite

Physical:
- Mounting: Two M6 holes 180° on 76 mm (3.0 inch) diameter
- Overall diameter: 90 mm (3.54 inches)
- Depth: 48 mm (1.89 inches)
- Net weight: 1.1 kg

Further Product Information Below

B & C DE36 (8 Ohm) Data Sheet (PDF)

B & C DE36 Technical Drawing (PDF)
