B&C DE200 1-Inch Compression Driver - 50W RMS, 16 Ohm

Name: B&C DE200 1-Inch Compression Driver - 50W RMS, 16 Ohm
Brand: B&C
SKU: JP101921
Price: 88.56 GBP
Availability: InStock

Price Each £73.80 (£88.56 Including VAT at 20%)

REF: JP101921

Quantity:

B&C DE200 1-Inch Compression Driver - 50W RMS, 8 Ohm

The B&C DE200 boasts legendary B&C technology made with their famously critical quality control, allowing loudspeaker designs with appropriately scaled performance.

Replacement Diaphragm: JP61364 (B&C MMD20016)

Click Here for Printer Friendly Version

B&C DE200 1-Inch Compression Driver Features

- 100 W continuous program power capacity
- 1-inch horn throat diameter
- 44 mm (1.7 inch) aluminium voice coil
- Titanium diaphragm
- 1000 - 18000 Hz response
- 106 dB sensitivity

B&C DE200 1-Inch Compression Driver Specifications

- Throat Diameter: 25 mm (1 inches)
- Nominal Impedance: 16 Ω
- Minimum Impedance: 10.9 Ω
- Nominal Power Handling: 50 W
- Continuous Power Handling: 100 W
- Sensitivity (1W/1m): 106.0 dB
- Frequency Range: 1.0 - 18 kHz
- Recommended Crossover: 1.6 kHz
- Voice coil Diameter: 44 mm (1.7 inches)
- Winding Material: Aluminium
- Inductance: 0.14 mH
- Diaphragm Material: Titanium
- Flux Density: 1.5 T
- Magnet Material: Ferrite

Physical:
- Mounting:
- Two M6 holes 180° on 76 mm (3.0 inch) diameter
- Three M6 holes 120° on 57 mm (2.2 in) diameter
- Overall diameter: 102 mm (4.0 inches)
- Depth: 61 mm (2.4 inches)
- Net weight: 1.75 kg

Further Product Information Below

B & C DE200 (16 Ohm) Data Sheet (PDF)

B & C DE200 Technical Drawing (PDF)
