B&C DE12 1-Inch Compression Driver - 25W RMS, 8 Ohm, Spade Terminals

Price Each £47.94 (£57.53 Including VAT at 20%)

REF: JP61018

Quantity:

B&C DE12 1-Inch Compression Driver - 25W RMS, 8 Ohm, Spade Terminals

The B&C DE12 boasts legendary B&C technology made with their famously critical quality control, allowing loudspeaker designs with appropriately scaled performance.

Replacement Diaphragm: JP61248 (B&C MMD0128)

Click Here for Printer Friendly Version

B&C DE12 1-Inch Compression Driver Features

- 50 W continuous program power capacity
- 1-inch horn throat diameter
- 36 mm (1.4 inch) aluminium voice coil
- Polyester diaphragm
- 1500 - 18000 Hz response
- 106 dB sensitivity

B&C DE12 1-Inch Compression Driver Specifications

- Throat Diameter: 25 mm (1 inch)
- Nominal Impedance: 8 Ω
- Minimum Impedance: 7.8 Ω
- Nominal Power Handling: 25 W
- Continuous Power Handling: 50 W
- Sensitivity (1W/1m): 106.0 dB
- Frequency Range: 1.5 - 18 kHz
- Recommended Crossover: 2.2 kHz
- Voice coil Diameter: 36 mm (1.4 inches)
- Winding Material: Aluminium
- Inductance: 0.14 mH
- Diaphragm Material: Mylar
- Flux Density: 1.45 T
- Magnet Material: Ferrite

Physical:
- Mounting: Two M5 holes 180° on 76 mm (3.0 inch) diameter
- Overall diameter: 90 mm (3.5 inches)
- Depth: 49 mm (2.0 inches)
- Net weight: 1.05 kg

Further Product Information Below

B & C DE12 (8 Ohm) Data Sheet (PDF)

B & C DE12 Technical Drawing (PDF)
