B&C DE120 1-Inch Compression Driver - 20W RMS, 8 Ohm

B&C DE120 1-Inch Compression Driver Features

- 40 W continuous program power capacity
- 1-inch horn throat diameter
- 36 mm (1.4 in) aluminium voice coil
- Mylar diaphragm
- 1500 - 18000 Hz response
- 106 dB sensitivity

B&C DE120 1-Inch Compression Driver Specifications

- Throat Diameter: 25 mm (1 inches)
- Minimum Impedance: 8 Ω
- Continuous Power Handling: 40 W
- Frequency Range: 2 - 18 kHz
- Voice Coil Diameter: 36 mm (1.4 inches)
- Inductance: 0.14 mH
- Flux Density: 1.9 T
- Min Frequency Range: 2 kHz
- Nominal Impedance: 8 Ω
- Nominal Power Handling: 20 W
- Sensitivity: 106 dB
- Recommended Crossover: 2 kHz
- Winding Material: Aluminium
- Diaphragm Material: Mylar
- Max Frequency Range: 18 kHz

Physical:
- Overall diameter: 71 mm (2.8 inches)
- Depth: 34 mm (1.34 inches)
- Net weight: 0.45 kg

Further Product Information Below

B & C DE120 Data Sheet (PDF)
