B&C DE110 1-Inch Compression Driver - 25W RMS, 8 Ohm

Price Each £55.43 (£66.52 Including VAT at 20%)

REF: JP61377

Quantity:

B&C DE110 1-Inch Compression Driver - 25W RMS, 8 Ohm

The B&C DE110 boasts legendary B&C technology made with their famously critical quality control, allowing loudspeaker designs with appropriately scaled performance.

Replacement Diaphragm: JP101985 (B&C MMDDE1108)

Click Here for Printer Friendly Version

B&C DE110 1-Inch Compression Driver Features

- 50 W continuous program power capacity
- Ultra Compact 60mm diameter
- 1-inch horn throat diameter
- 36 mm (1.4 inch) aluminium voice coil
- HT Polymer diaphragm
- 2000 - 18000 Hz response
- 106 dB sensitivity

B&C DE110 1-Inch Compression Driver Specifications

- Throat Diameter: 25 mm (1 inch)
- Nominal Impedance: 8 Ω
- Minimum Impedance: 8.0 Ω
- Nominal Power Handling: 25 W
- Continuous Power Handling: 50 W
- Sensitivity (1W/1m): 106.0 dB
- Frequency Range: 2 - 18 kHz
- Recommended Crossover: 2.0 kHz
- Voice coil Diameter: 36 mm (1.4 inches)
- Winding Material: Aluminium
- Inductance: 0.14 mH
- Diaphragm Material: HT Polymer
- Flux Density: 1.8 T
- Magnet Material: Neodymium Ring

Physical:
- Mounting: Two M5 holes 180° on 52 mm (2.05 inch) diameter
- Overall diameter: 60 mm (2.36 inches)
- Depth: 35 mm (1.38 inches)
- Net weight: 0.32 kg

Further Product Information Below

B & C DE110 (8 Ohm) Data Sheet (PDF)

B & C DE110 Technical Drawing (PDF)
