B&C 6PS38 6.5-Inch Speaker Driver - 150W RMS, 8 Ohm, Spade Terminals

Name: B&C 6PS38 6.5-Inch Speaker Driver - 150W RMS, 8 Ohm, Spade Terminals
Brand: B&C
SKU: JP61437
Price: 82.14 GBP
Availability: InStock

Price Each £68.45 (£82.14 Including VAT at 20%)

REF: JP61437

Quantity:

B&C 6PS38 6.5-Inch Speaker Driver - 150W RMS, 8 Ohm

The B&C 6PS38 6.5-Inch Speaker Driver boasts legendary B&C technology made with their famously critical quality control, allowing loudspeaker designs with appropriately scaled performance.

Recone Kit: JP61154 (B&C RCK06PS388)

Click Here for Printer Friendly Version

B&C 6PS38 6.5-Inch Speaker Driver Features

- 300W continuous power capacity
- 38 mm (1.5 inches) aluminium voice coil
- 70 - 5000 Hz frequency resposnse
- 94 dB sensitivity
- Waterproofed on front of cone

B&C 6PS38 6.5-Inch Speaker Driver Specifications

- Nominal diameter 170 mm (6.69 inches)
- Nominal impedance: 8 Ω
- Minimum impedance: 6.6 Ω
- Nominal power handling: 150 W
- Continuous power handling: 300 W
- Sensitivity (1W/1m): 94.0 dB
- Frequency range: 70 - 5000 Hz
- Voice coil diameter: 38 mm (1.5 inches)
- Winding material: Aluminium
- Former material: Glass Fibre
- Winding depth: 12 mm (0.49 inches)
- Magnetic gap depth: 6 mm (0.24 inches)
- Flux density: 1.4 T
- Connection: Spade Terminals

Design:
- Surround shape: Roll
- Cone shape: Radial
- Magnet material: Ferrite Ring
- Spider: Single
- Pole design: Straight Pole
- Woofer cone treatment: WP Waterproof Front Side
- Recommended enclosure: 9.0 dm³
- Recommended tuning: 80 Hz

Parameters:
- Fs 75 Hz
- Re: 5.4 Ω
- Qes: 0.31
- Qms: 11.7
- Qts: 0.3
- Vas: 8.0 dm³
- Sd: 132.0 cm²
- η₀: 1.0 %
- Xmax: ± 6.0 mm
- Xvar: ± 7.5 mm
- Mms: 14 g
- Bl: 10.8 Txm
- Le: 0.6 mH
- EBP: 241 Hz

Physical:
- Overall diameter: 187 mm
- Bolt circle diameter: 172 mm
- Baffle cutout diameter: 145.0 mm
- Depth: 82 mm (3.23 inches)
- Flange and gasket thickness: 9 mm (0.35 inches)
- Air volume occupied by driver: 0.8 dm³
- Net weight: 2.2 kg

Further Product Information Below

B & C 6PS38 (8 Ohm) Data Sheet (PDF)

B & C 6PS38 Technical Drawing (PDF)
