B&C 6MD38 6.5-Inch Speaker Driver - 120W RMS, 16 Ohm

Name: B&C 6MD38 6.5-Inch Speaker Driver - 120W RMS, 16 Ohm
Brand: B&C
SKU: JP101840
Price: 80.1 GBP
Availability: InStock

Price Each £66.75 (£80.10 Including VAT at 20%)

REF: JP101840

Quantity:

B&C 6MD38 6.5-Inch Speaker Driver - 120W RMS, 16 Ohm

The B&C 6MD38 6.5-Inch Speaker Driver boasts legendary B&C technology made with their famously critical quality control, allowing loudspeaker designs with appropriately scaled performance.

Recone Kit: JP101955 (B&C RCK06MD3816)

Click Here for Printer Friendly Version

B&C 6MD38 6.5-Inch Speaker Driver Features

- 240 W continuous program power capacity
- 38 mm (1.5 inches) aluminium voice coil
- 150 - 6000 Hz response
- 96 dB sensitivity

B&C 6MD38 6.5-Inch Speaker Driver Specifications

- Nominal diameter: 170 mm (6.5 inches)
- Nominal impedance: 16 Ω
- Minimum impedance: 13.3 Ω
- Nominal power handling: 120 W
- Continuous power handling: 240 W
- Sensitivity (1W/1m): 95.0 dB
- Frequency range: 150 - 6000 Hz
- Voice coil diameter: 38 mm
- Winding material: Aluminium
- Former material: Glass Fibre
- Winding depth: 9 mm
- Magnetic gap depth: 6 mm
- Flux density: 1.4 T
- Connection: Spade Terminals

Design:
- Surround shape: Triple Roll
- Cone shape: Exponential
- Magnet material: Ferrite
- Spider: Single
- Pole design: T-Pole
- Woofer cone treatment: None

Parameters:
- Fs: 150 Hz
- Re: 11.7 Ω
- Qes: 0.61
- Qms: 2.8
- Qts: 0.5
- Vas: 2.3 dm³
- Sd: 132.0 cm²
- η₀: 1.4 %
- Xmax: 3.5 mm
- Xvar: 2.0 mm
- Mms; 11 g
- Bl: 14.5 Txm
- Le: 0.4 mH
- EBP: 245 Hz

Physical:
- Overall diameter: 187 mm
- Bolt circle diameter: 172 mm
- Baffle cutout diameter: 145.0 mm
- Depth: 82 mm
- Flange and gasket thickness: 9 mm
- Air volume occupied by driver: 0.8 dm³
- Net weight: 2.2 kg

Further Product Information Below

B & C 6MD38 (16 Ohm) Data Sheet (PDF)

B & C 6MD38 Technical Drawing (PDF)
