B&C 15PS100 15-Inch Speaker Driver - 700W RMS, 8 Ohm, Spring Terminals

The B&C 15PS100 15-Inch Speaker Driver boasts legendary B&C technology made with their famously critical quality control, allowing loudspeaker designs with appropriately scaled performance.

Recone Kit: JP61197 (B&C RCK15PS1008)

Click Here for Printer Friendly Version

B&C 15PS100 15-Inch Speaker Driver Features

- 1400 W continuous program power capacity
- 100 mm (4 inch) copper voice coil
- 35 - 1500 Hz response
- 95 dB sensitivity
- Waterproofed cone
- Double silicone spider with optimized compliance

B&C 15PS100 15-Inch Speaker Driver Specifications

- Nominal Basket Diameter: 380 mm (15.0 inches)
- Nominal Impedance: 8 Ω
- Minimum Impedance: 6.5 Ω
- Nominal Power Handling: 700 W
- Continuous Power Handling: 1400 W
- Frequency Response: 35 - 1500 Hz
- Sensitivity: 95.0 dB
- Voice Coil Diameter: 100 mm (4.0 inches)
- Winding Material: Copper
- Former Material: Glass Fibre
- Winding Depth: 21 mm (0.83 inches)
- Magnetic Gap Depth: 11 mm (0.4 inches)
- Connection: Spring Terminals

Design:
- Surround shape: Triple Roll
- Cone shape: Radial
- Magnet material: Ferrite Ring
- Spider: Double Silicone
- Pole design: T-Pole
- Waterproofing Treatment: TWP Waterproof Both Sides
- Recommended enclosure: 120.0 dm³
- Recommended tuning: 35 Hz

Parameters:
- Fs: 39 Hz
- Re: 5.2 Ω
- Qes: 0.47
- Qms: 6.0
- Qts: 0.43
- Vas: 103.0 dm³
- Sd: 855.0 cm²
- η₀: 1.35 %
- Xmax: ± 8.0 mm
- Xvar: ± 6.5 mm
- Mms: 160.0 g
- Bl: 21.2 Txm
- Le: 2.0 mH
- EBP: 82 Hz

Physical:
- Overall diameter: 393 mm (15.5 inches)
- Bolt circle diameter: 374 mm (14.7 inches)
- Baffle cutout diameter: 354 mm (13.9 inches)
- Depth: 168 mm (6.6 inches)
- Flange and gasket thickness: 16 mm (0.62 inches)
- Air volume occupied by driver: 6.3 dm³
- Net weight: 9.8 kg

Further Product Information Below

B & C 15PS100 (8 Ohm) Data Sheet (PDF)

B & C 15PS100 Technical Drawing (PDF)
