B&C 15NDL88 15-Inch Speaker Driver - 700W RMS, 8 Ohm, Spade Terminals

Name: B&C 15NDL88 15-Inch Speaker Driver - 700W RMS, 8 Ohm, Spade Terminals
Brand: B&C
SKU: JP61465
Price: 235.24 GBP
Availability: InStock

Price Each £196.03 (£235.24 Including VAT at 20%)

REF: JP61465

Quantity:

B&C 15NDL88 15-Inch Speaker Driver - 700W RMS, 8 Ohm, Spade Terminals

The B&C 15NDL88 15-Inch Speaker Driver is perfectly balanced for the modern loudspeaker systems. Incorporating a high temperature neodymium magnet inside the 3.5-inch (88mm) voice coil reduces the amount of steel needed in the motor structure, saving cost and weight. Impressive low frequency output and midrange extension to meet with almost any driver for two way applications is the hallmark of this new performance-oriented woofer line from B&C Speakers. Do more, with less, with the NDL88 series.

Recone Kit: JP103980 (B&C RCK15NDL888)

Click Here for Printer Friendly Version

B&C 15NDL88 15-Inch Speaker Driver Features

- 1400 W continuous program power capacity
- 88 mm (3.5 in) aluminium voice coil
- 45 - 3000 Hz response
- 99 dB sensitivity
- Waterproofed on front of cone
- Neodymium magnet allows a very light yet powerful motor assembly
- Double silicone spider with optimized compliance
- Aluminum demodulating ring allows a very low distortion figure

B&C 15NDL88 15-Inch Speaker Driver Specifications

- Nominal Basket Diameter: 380 mm (15.0 inches)
- Nominal Impedance: 8 Ω
- Minimum Impedance: 6.0 Ω
- Nominal Power Handling: 700 W
- Continuous Power Handling: 1400 W
- Frequency Response: 45 - 3000 Hz
- Sensitivity: 99.0 dB
- Voice Coil Diameter: 88 mm (3.5 inches)
- Winding Material: Aluminium
- Former Material: Glass Fibre
- Winding Depth: 21 mm (0.83 inches)
- Magnetic Gap Depth: 10 mm (0.39 inches)
- Flux Density: 1.05 T
- Connection: Spade Terminals

Design:
- Surround shape: Triple Roll
- Cone shape: Exponential
- Magnet material: Neodymium Inside Slug
- Spider: Double Silicone
- Pole design: T-Pole
- Waterproofing Treatment: WP Waterproof Front Side
- Recommended enclosure: 125.0 dm³
- Recommended tuning: 45 Hz

Parameters:
- Fs: 45 Hz
- Re: 5.0 Ω
- Qes: 0.36
- Qms: 6.1
- Qts: 0.34
- Vas: 126.0 dm³
- Sd: 855.0 cm²
- η₀: 3.1 %
- Xmax: ± 8.0 mm
- Xvar: ± 10.0 mm
- Mms: 102.0 g
- Bl: 20.1 Txm
- Le: 1.25 mH
- EBP: 125 Hz

Physical:
- Overall diameter: 393 mm (15.5 inches)
- Bolt circle diameter: 374 mm (14.7 inches)
- Baffle cutout diameter: 354 mm (13.9 inches)
- Depth: 177 mm (6.97 inches)
- Flange and gasket thickness: 13 mm (0.51 inches)
- Air volume occupied by driver: 3.5 dm³
- Net weight: 4.6 kg

Further Product Information Below

B & C 15NDL88 (8 Ohm) Data Sheet (PDF)

B & C 15NDL88 Technical Drawing (PDF)
