Studiomaster Club XS 16+ 16-Input Analogue Mixing Desk with Bluetooth & Digital FX

Name: Studiomaster Club XS 16+ 16-Input Analogue Mixing Desk with Bluetooth & Digital FX
Brand: Studiomaster
Price: 307.13 GBP
Availability: InStock

Price Each £255.94 (£307.13 Including VAT at 20%)

REF: JP106566

Quantity:

Studiomaster Club XS 16+ 16-Input Analogue Mixing Desk with Bluetooth & Digital FX

The Studiomaster Club XS 16+ 16-Input Analogue Mixing Desk with Bluetooth & Digital FX takes affordable small format analogue mixers to new height and is the perfect mixer for any live performance and home recording situation.
The Club XS+ models incorporate all of the great features of the standard Club range, now with the inclusion of a DSP On/Off foot switch socket and an aesthetic overhaul, redesigned control knobs and finished in Studiomaster digital black.
Compact, portable mixing consoles featuring 5 to 16 inputs, Bluetooth connectivity, on-board DSP effects and USB/SD card playback and recording functions. 3 band EQ, 2 auxiliaries, balanced mic/line connectors, compressor control, and a useful mute switch on all Mic and line input channels, 2 band EQ with 2 auxiliaries for both stereo channels. There are also balanced XLR connectors for the main outputs, jacks for auxiliaries and control room, and phono connectors for analogue record and playback.

Click Here for Printer Friendly Version

Studiomaster Club XS 16+ 16-Input Analogue Mixing Desk with Bluetooth & Digital FX Features

- 16 inputs: 12 mic channels, 2 stereo channels
- 3 Auxiliary busses for monitoring and internal/external effects processing
- Professional balanced outputs
- High quality microphone pre amps with enhanced compression and gain controls and 3 band EQ on all microphone channels
- 60mm smooth faders
- PFL and Mute control on every channel
- 16 in built DSP effects
- Foot switch socket for DSP on/off control
- Bluetooth playback connectivity
- USB/SD media player and recorder
- Internal power supply

Studiomaster Club XS 16+ 16-Input Analogue Mixing Desk with Bluetooth & Digital FX Specifications

- Inputs: 16
  - Mic Inputs: 12
  - Stereo Inputs: 2
- Mic Gain Range: 6dB to 50dB
- Line Gain Range: 10dB to 34dB
- EIN: -100dB
- Frequency Responce: 10Hz – 20kHz (+1/-3dB)
- THD Mic Channel: <0.1%
- Signal to Noise Ratio: 80dB
- Output Levels:
  - Balanced: +26dB
  - Unbalanced: +20dB
- EQ:
  - Hi: 12kHz
  - Mid: 2.5kHz
  - Low: 45Hz
  - Low cut: 80Hz
- USB/SD: MP3 Audio playback
- Record: To USB drive or SD card (128 kbps mono)
- DSP Effects: 16 DSP effects
- Power Requirements: 100V – 240V ~

Physical:
- Dimensions (W x H x D): 525 x 80 x 390 mm
- Weight: 7.3 kg

Further Product Information Below

Studiomaster Club XS 16+ Manual (PDF)
