Showtec Phantom 1220 Zoombar RGBW LED Batten with Motorised Tilt

Showtec Phantom 1220 Zoombar RGBW LED Batten with Motorised Tilt Features

- 12x 20 W RGBW Moving LED Bar
- Motorised zoom
- Fast motorised tilt
- Full Pixel control for advanced light designers
- Quick-Lock brackets

Showtec Phantom 1220 Zoombar RGBW LED Batten with Motorised Tilt Specifications

Source:
- Light Source Type: LED
- Light Source Quantity: 12
- Light Source Power: 20 W
- LED Colour Type: RGBW
- Refresh Rate (Max.): 15 kHz
- Illuminance @ 2 m: 57000 lx
- Luminous Flux (Total): 45000 lm

Optical:
- Beam Angle (Circular): 50 °
- Zoom Type: Motorised
- Zoom Minimum: 5 °
- Zoom Maximum: 50 °

Control and Programming:
- Control Mode: Auto, DMX, Manual, Master Slave
- DMX Channels: 19, 24, 72, 84, 129
- Protocols: DMX, RDM
- Display: LCD
- Dim Curve: Linear, Square, I-Square, S-Curve
- Zone Control (Sections): 12
- Dimmer Resolution: 16 bit

Dynamic Effects:
- Dimmer: 0-100 %
- Strobe: 0-20 Hz

Movement:
- Tilt: 210 °
- Pan/Tilt Resolution: 16-bit

Electrical Specifications and Connections:
- Power Supply: 100-240 V AC 50/60 Hz
- Power Consumption: 240 W
- Power Connector In: PowerCON Blue
- Power Connector Out: PowerCON Grey
- DMX Connector: XLR 3P In/Out, XLR 5P In/Out
- DMX Connector In: XLR 3P, XLR 5P
- DMX Connector Out: XLR 3P, XLR 5P

Mechanical Specifications:
- Length: 1000 mm
- Height: 233 mm
- Weight: 13.2 kg
- IP Rating: IP20 (indoor use only)
- Housing: Metal, Plastic

Product Properties:
- Cooling: Axial fan

Rigging:
- Mounting Options: Quick-Lock
- Safety Attachment: Yes

Thermal Specifications:
- Maximum Ambient Temperature: 40 °C

Further Product Information Below

Showtec Phantom 1220 Zoombar Manual (PDF)

Showtec Phantom 1220 Zoombar RGBW LED Batten with Motorised Tilt Supplied With

- PowerCON cable
- Quick-Lock Bracket
