Showtec Shark Scan 1 LED Scanner

Showtec Shark Scan 1 LED Scanner Features

- Compact 100 W LED Scanner
- 7 rotating gobos + open
- 8 colours + white
- 3-facet prism
- Motorised focus

Showtec Shark Scan 1 LED Scanner Specifications

Source:
- Light Source Type: LED
- Light Source Quantity: 1
- Light Source Power: 100 W
- LED Colour Type: White
- Illuminance:
  - 2 m: 8573 lx
  - 3 m: 3810 lx
  - 5 m: 1372 lx
- Luminous Flux (Total): 2245 lm
- CRI: 80
- CCT: 10000 K

Optical:
- Beam Angle (Circular): 18 °
- Focus: Motorised

Control and Programming:
- Control Mode:
  - Auto
  - DMX
  - Master/Slave
  - Sound
- DMX Channels: 8, 14
- Protocols: DMX
- Display: OLED

Dynamic Effects:
- Dimmer: 0-100 %
- Strobe: 0-25 Hz
- Prism 1: 3-facet
- Prism Index & Rotate: No
- Colour System: Colour Wheel
- Colour Wheel Index & Rotate: Yes
- Dichroic Colour Wheel 1: 8 + Open
- Gobo System: Glass + Metal
- Gobo Wheel Index & Rotate: Yes
- Gobo Wheel 1: 7 + Open

Movement:
- Pan: 160 °
- Tilt: 50 °
- Pan/Tilt Resolution: 16-bit

Electrical Specifications and Connections:
- Power Supply: 100-240 V AC 50/60 Hz
- Power Consumption: 116 W
- Fuse: 4 A
- Power Connector In: Power Pro Blue
- Power Connector Out: Power Pro Grey
- DMX Connector: XLR 3P In/Out
- DMX Connector In: XLR 3P
- DMX Connector Out: XLR 3P

Mechanical Specifications:
- IP Rating: IP20 (indoor use only)
- Housing: Metal, Plastic
- Colour: Black
- Dimensions (W x H x D): 250 x 297 x 380 mm
- Weight: 6.2 kg

Product Properties:
- Cooling: Convection/Axial fan

Rigging:
- Mounting Options: Clamp

Thermal Specifications:
- Maximum Ambient Temperature: 40 °C
- Minimum Ambient Temperature: -5 °C

Further Product Information Below

Showtec Shark Spot One Manual (PDF)

Showtec Shark Scan 1 LED Scanner Supplied With

- Power Pro Cable
- Bracket
