Showtec Phantom 3R Beam Discharge Moving Head, 150W

Name: Showtec Phantom 3R Beam Discharge Moving Head, 150W
Brand: Showtec
Price: 838.39 GBP
Availability: InStock

Price Each £698.66 (£838.39 Including VAT at 20%)

REF: JP109235

Quantity:

Showtec Phantom 3R Beam Discharge Moving Head, 150W

The Showtec Phantom 3R Beam Discharge Moving Head is a compact, yet powerful Beam Moving Head with a bright 150 watt discharge light engine providing a highly focused 3.5° beam angle, suitable for indoor venues. Its motorised frost filter and focus converts the tight beam to a wide wash for covering large areas, suitable for various applications. The Phantom 3R Beam is equipped with 17 gobos + open, 14 colours + white, 16-facet circular rotating prism and various colour effects, such as split colours and rainbow flow, for creating stunning optical effects. Optionally, you can upgrade the Phantom 3R Beam for wireless DMX communications.

Click Here for Printer Friendly Version

Showtec Phantom 3R Beam Discharge Moving Head Features

- Compact, powerful 150 W Beam Moving Head
- Motorised frost filter and focus
- 16-facet circular rotating prism
- 17 fixed gobos + open
- 14 colours + white

Showtec Phantom 3R Beam Discharge Moving Head, 150W Specifications

Source:
- Light Source Type: Discharge
- Light Source Quantity: 1
- Light Source Power: 150 W
- Life Expectancy: 6000 h
- Luminous Flux (Total): 9200 lm
- CCT: 8600 K

Optical:
- Beam Angle Max. (Circular): 3.5 °
- Frost: Yes
- Focus: Motorised

Control and Programming:
- Control Mode:
  - Auto
  - DMX
  - Manual
  - Master/Slave
  - Sound
- DMX Channels: 10, 14
- Protocols: DMX
- Wireless: Optional
- Display: LCD

Dynamic Effects:
- Dimmer: 0-100 %
- Strobe: 0-20 Hz
- Shutter: Yes
- Prism 1: 16-facte Circulair
- Prism Index & Rotate: Yes
- Colour System: Colour Wheel
- Colour Wheel Index & Rotate: Yes
- Dichroic Colour Wheel 1: 14 + Open
- Gobo System: Metal
- Gobo Wheel Index & Rotate: Yes
- Gobo Wheel 1: 17 + Open

Movement:
- Pan: 540 °
- Tilt: 270 °
- Pan/Tilt Resolution: 16-bit

Electrical Specifications and Connections:
- Power Supply: 100-240 V AC 50/60 Hz
- Power Consumption: 255 W
- Fuse: 4 A
- Power Connector In: Power Pro Blue
- Power Connector Out: Power Pro Grey
- DMX Connector: XLR 3P In/Out
- DMX Connector In: XLR 3P
- DMX Connector Out: XLR 3P

Mechanical Specifications:
- Dimensions (W x H x D): 210 x 420 x 325 mm
- Weight: 13 kg
- IP Rating: IP20 (indoor use only)
- Housing: Metal, Plastic
- Colour: Black

Product Properties:
- Cooling: Axial fan

Rigging:
- Mounting Options: Quick-Lock
- Safety Attachment: Yes

Thermal Specifications:
- Maximum Ambient Temperature: 40 °C
- Maximum Surface Temperature: 70 °C
- Minimum Distance to Objects: 10 m

Further Product Information Below

Showtec Phantom 3R Beam Manual (PDF)

Showtec Phantom 3R Beam Discharge Moving Head Supplied With

- Power Pro Cable
- Quick-Lock Bracket
