Showtec Galactic TXT RGB Text Laser

Showtec Galactic TXT RGB Text Laser Features

- 300 mW RGB text laser
- Custom and preset animations
- 128 preset animations & symbols
- Clock, countdown and date function
- Zoom, movement, wave, drawing and colour effects

Showtec Galactic TXT RGB Text Laser Specifications

Source:
- Laser Power: 300 mW
- Laser Source: Diode, DPSS
- Laser Modulation: TTL
- Laser Class: 3B
- Laser Colour: Red, Green, Blue, White, Yellow, Purple, Cyan
- Laser Power (Total): 300 mW
- Laser Power (Red): 150 mW
- Laser Wavelength (Red): 638 nm
- Laser Power (Green): 50 mW
- Laser Wavelength (Green): 532 nm
- Laser Power (Blue): 100 mW
- Laser Wavelength (Blue): 450 nm

Control and Programming:
- Control Mode:
  - Auto
  - DMX
  - Master Slave
  - Sound
- DMX Channels: 17
- Display: 7-segment, LED

Movement:
- Laser Scanner Speed: 10 K
- Laser Scan Angle (Max.): 30 °

Electrical Specifications and Connections:
- Power Supply: 100-240 V AC 50/60 Hz
- Power Consumption: 25 W
- Power Connector In: IEC
- DMX Connector: XLR 3P In/Out
- DMX Connector In: XLR 3P
- DMX Connector Out: XLR 3P
- Data Connector In: Dedicated data connector

Product Properties:
- Cooling: Convection/Axial fan
- Safety Features: Interlock, Key Switch, Safety Eye
- Laser Scanner: 10 kpps

Thermal Specifications:
- Maximum Ambient Temperature: 35 °C (95 °F)

Rigging:
- Mounting Options: Clamp, Surface
- Safety Attachment: Yes

Certification / Qualification:
- Laser Classification Standard: EN-IEC 60825-1:2014
- NOHD: 92 m (301.837 ft)
- MPE (for Exposure Duration of 0,25 s): 25 W·m?² (0.0037 W·ft?²)

Physical:
- IP Rating: IP20 (indoor use only)
- Housing: Metal, Plastic
- Colour: Black
- Dimensions (W x H x D): 225 x 185 x 185 mm
- Weight: 1.9 kg

Further Product Information Below

Showtec Galactic TXT RGB Text Laser Manual (PDF)

Showtec Galactic TXT RGB Text Laser Suplied With

- IEC Cable
- Interlock connector, Interlock key(s)
- Keyboard (PS2)
- Bracket
