Showtec Galactic RGB-6-751 Full-Colour Fat Beam Laser

Showtec Galactic RGB-6-751 Full-Colour Fat Beam Laser Features

- 600 mW Full Colour Fat Beam Lasers
- Six individually controllable beams
- DMX, Master/slave, Colour, and Auto modes
- 32 internal patterns
- Intensity, zoom, and 3-axis rotation

Showtec Galactic RGB-6-751 Full-Colour Fat Beam Laser Specifications

Source:
- Laser Source: Diode
- Laser Modulation: Analog
- Laser Class: 3B
- Laser Colour: Red, Green, Blue
- Laser Power (Total): 600 mW
- Laser Power (Red): 180 mW
- Laser Wavelength (Red): 638 nm
- Laser Power (Green): 40 mW
- Laser Wavelength (Green): 520 nm
- Laser Power (Blue): 380 mW
- Laser Wavelength (Blue): 450 nm
- Beam Diameter at Aperture: 5 mm (0.197?)
- Beam Divergence: 2 mrad

Control and Programming:
- Control Mode:
  - Built-in Program
  - DMX
  - Master Slave
  - Sound
- DMX Channels: 7, 9, 12, 36, 48, 54, 66
- Display: LCD

Electrical Specifications and Connections:
- Power Supply: 100-240 V AC 50/60 Hz
- Power Consumption: 108 W
- Power Connector In: Power Pro Blue
- Power Connector Out: Power Pro Grey
- DMX Connector: XLR 3P In/Out
- DMX Connector In: XLR 3P
- DMX Connector Out: XLR 3P

Product Properties:
- Cooling: Axial fan
- Safety Features:
  - Interlock
  - Key Switch
  - Safety Eye

Rigging:
- Mounting Options: Bracket, Quick-Lock

Thermal Specifications:
- Maximum Ambient Temperature: -40 °C (-40 °F)

Certification / Qualification:
- Laser Classification Standard: EN-IEC 60825-1:2014+A11:2021
- NOHD: 136 m (446.194 ft)
- MPE (for Exposure Duration of 0,25 s): 25.4 W·m?² (0.0037 W·ft?²)

Physical:
- IP Rating: IP20 (indoor use only)
- Housing: ABS, Aluminium
- Colour: Black
- Dimensions (W x H x D): 1000 x 123 x 123 mm
- Weight: 11.5 kg

Further Product Information Below

Showtec Galactic RGB-6-751 Manual (PDF)

Showtec Galactic RGB-6-751 Full-Colour Fat Beam Laser Suplied With

- powerCON cable
