Showtec Galactic RBP-180 MkII Red/Blue/Purple Laser

Showtec Galactic RBP-180 MkII Red/Blue/Purple Laser Features

- 180 mW laser
- Red, Blue and Purple colour output
- 32 patterns and built-in programs
- Rotate and X/Y roll function
- 30° scan angle with manual zoom

Showtec Galactic RBP-180 MkII Red/Blue/Purple Laser Specifications

Source:
- Laser Power: 180 mW
- Laser Source: Diode
- Laser Modulation: TTL
- Laser Class: 3B
- Laser Colour: Red, Blue, Purple
- Laser Power (Total): 180 mW
- Laser Power (Red): 100 mW
- Laser Wavelength (Red): 650 nm
- Laser Power (Blue): 80 mW
- Laser Wavelength (Blue): 450 nm

Control and Programming:
- Control Mode:
  - Auto
  - Built-in Program
  - Master Slave
  - Remote
  - Sound
- DMX Channels: 10
- Display: 7-segment, LED

Movement:
- Laser Scan Angle (Max.): 30 °

Electrical Specifications and Connections:
- Power Supply: 100-240 V AC 50/60 Hz
- Power Consumption: 16 W
- Power Connector In: IEC
- DMX Connector: XLR 3P In/Out
- DMX Connector In: XLR 3P
- DMX Connector Out: XLR 3P

Product Properties:
- Cooling: Axial fan
- Safety Features: Interlock, Key Switch, Safety Eye

Thermal Specifications:
- Maximum Ambient Temperature: 35 °C (95 °F)

Rigging:
- Mounting Options: Bracket, Clamp, Surface
- Safety Attachment: Yes

Physical:
- IP Rating: IP20 (indoor use only)
- Housing: Metal
- Colour: Black
- Dimensions (W x H x D): 168 x 158 x 148 mm
- Weight: 1.3 kg

Further Product Information Below

Showtec Galactic RBP-180 MkII Manual (PDF)

Showtec Galactic RBP-180 MkII Red/Blue/Purple Laser Suplied With

- IEC Cable
- Interlock connector, Interlock key(s)
- Bracket
