Showtec Cameleon Spot 7Q6 Tour RGBWA+UV LED Spot, 7x 12W - IP65

Showtec Cameleon Spot 7Q6 Tour RGBWA+UV LED Spot Features

- 7x 12 W RGBWA-UV LED Spot
- IP65 (dust and water resistant, fit for outdoor use)
- 15° fixed beam angle
- Dimmer and strobe function
- Manual, DMX, IR and Master/Slave control

Showtec Cameleon Spot 7Q6 Tour RGBWA+UV LED Spot Specifications

Source:
- Light Source Type: LED
- Light Source Quantity: 7
- Light Source Power: 12 W
- LED Colour Type: RGBWAUV
- Refresh Rate: 3000 Hz
- Luminous Flux:
  - Total: 1850 lm
  - Red: 500 lm
  - Green: 800 lm
  - Blue: 195 lm
  - White: 725 lm
  - Amber: 575 lm
  - UV: 55 lm

Optical:
- Beam Angle (Circular): 15 °

Control and Programming:
- Control Mode:
  - Auto
  - DMX
  - Manual
  - Master/Slave
  - Remote
- DMX Channels: 6, 8, 13
- Protocols: DMX, RDM
- Display: OLED

Dynamic Effects:
- Dimmer: 0-100 %
- Strobe: 0-20 Hz

Electrical Specifications and Connections:
- Power Supply: 100-240 V AC 50/60 Hz
- Power Consumption: 65 W
- Power Connector In: Power Pro True
- Power Connector Out: Power Pro True
- DMX Connector: XLR 3P In/Out
- DMX Connector In: XLR 3P
- DMX Connector Out: XLR 3P

Mechanical Specifications:
- Dimensions (W x H x D): 160 x 242 x 225 mm
- Weight: 3.3 kg
- IP Rating: IP65
- Housing: Aluminium die-cast
- Colour: Black

Product Properties:
- Cooling: Convection

Thermal Specifications:
- Maximum Ambient Temperature: 40 °C
- Minimum Operating Temperature: -5 °C

Further Product Information Below

Showtec Cameleon Spot 7Q6 Tour Manual (PDF)

Showtec Cameleon Spot 7Q6 Tour RGBWA+UV LED Spot Supplied With

- Power Pro True Cable
