Penn Elcom 13A Power Distribution Unit (PDU16-6UK)

Name: Penn Elcom 13A Power Distribution Unit (PDU16-6UK)
Brand: Penn Elcom
SKU: 0759478555368
Price: 316.74 GBP
Availability: InStock

Price Each £263.95 (£316.74 Including VAT at 20%)

REF: JP102141

Quantity:

Penn Elcom 13A Power Distribution Unit (PDU16-6UK), 20A AC Pro Stage and Truss Mount Plug Board. This power distribution board is built for professional event use, with a super tough steel case and high-spec components. Designed for mounting, it comes with a rear M10 captive nut fixing for coupler attachment to truss and stage fixings. Also has side slots for velcro or cable ties to help secure the unit. Suitable for use with the GL3008 half coupler with M10 recess. When using the link output the combined load of a 'Daisy Chain' must not exceed 20A.

Click Here for Printer Friendly Version

13A Power Distribution Unit (PDU16-6UK) Features

- 6 x 13A UK sockets
- Neutrik 20A PowerCON in and out link
- 16A illuminated thermal breaker for circuit protection

13A Power Distribution Unit (PDU16-6UK) Specifications

- Voltage: 250V max
- Frequency: 50/60HZ
- Maximum combined load: Current 20A
- Dimensions (H x W x D): 44mm x 166mm x 243mm
- Weight: 1.5kg
