Neutrik EtherCON Cable Connector RJ45 Carrier NE8MX6-B-T

Name: Neutrik EtherCON Cable Connector RJ45 Carrier NE8MX6-B-T
Brand: Neutrik
SKU: 0735202934371
Price: 16.27 GBP
Availability: InStock

Price Each £13.56 (£16.27 Including VAT at 20%)

REF: JP104605

Quantity:

Neutrik EtherCON Cable Connector RJ45 Carrier NE8MX6-B-T, An black chromium EtherCON CAT6A cable connector self-termination for insulation diameter =1.1 mm. The set NE8MX6 consists of a cable plug carrier offering a robust metal shell, proven Neutrik chuck-type strain relief and a CAT6A compliant RJ45 plug. The set is suitable for a cable diameter range of 7mm to 9.5mm and wire gauge of AWG26/1 - AWG24/1 (solid) or AWG27/7 - AWG24/7 (stranded). Note! Does not intermate with the CAT6 chassis connectors NE8FDY-C6 and NE8FDY-C6-B.

Click Here for Printer Friendly Version

Neutrik EtherCON Cable Connector RJ45 Carrier NE8MX6-B-T Features
- Ruggedized connector with CAT6A component compliance according to ISO/IEC 11801 and TIA/EIA 568-C.2
- oE++ compliant according to 802.3bt Type4
- IP65 protected when mated with NE8FDX-P6-W or NE8FDX-Y6-W
- Rugged latch lock system million fold proven
- Intermateable with the existing EtherCON CAT5 range (Note! Does not intermate with the CAT6 chassis connectors NE8FDY-C6 and NE8FDY-C6-B)
- Unique Neutrik chuck-type strain relief

Neutrik EtherCON Cable Connector RJ45 Carrier NE8MX6-B-T Specifications
- Cable overall diameter: 7.0mm - 9.5mm
- Protection class: IP65 (in combination with NE8FDX-*6-W)
- Temperature range: -40°C to +70°C
