elumen8 ISCHL Distribution Box 32A 3PH to 1 x 32A and 4 x 16A 1PH RCBO

elumen8 ISCHL Distribution Box 32A 3PH to 1 x 32A and 4 x 16A 1PH RCBO Features
- Handy, robust and lightweight distribution box made of shock-resistant polyamide
- High-grade steel folding carry handle
- 3 modules under clear MCB window
- IP44 rated
- Stackable design
- Made in the EU

elumen8 ISCHL Distribution Box 32A 3PH to 1 x 32A and 4 x 16A 1PH RCBO Specifications
- Input: 32A 415V~50/60Hz 5-Pin 3P+N+E IP44 inlet
- Pass Through: 32A 415V~50/60Hz 5-Pin 3P+N+E IP67 chassis socket
- Outputs:
1 x 32A 220-250V~50/60Hz 2P+E IP44 sockets each protected by a 32A 30mA 2P RCBO,
4 x 16A 220-250V~50/60Hz 2P+E IP44 sockets each protected by a 16A 30mA 2P RCBO type C
- Dimensions (H x W x D): 200 x 300 x 300mm
- Weight: 2.9kg
