JBL Control 68HP 8-Inch Coaxial Pendant Speaker, 250W @ 8 Ohms or 70V / 100V Line - Black

Price Per Pair £944.44 (£1,133.33 Including VAT at 20%)

REF: JP108634

Quantity:

JBL Control 68HP 8-Inch Coaxial Pendant Speaker, 250W @ 8 Ohms or 70V / 100V Line - Black

The JBL Control 68HP 8-Inch Coaxial Pendant Speaker provides high output, high power handling, superior clarity and consistent coverage in rooms with open-architecture ceilings, live spaces and other locations where a pendant loudspeaker is desired. Common applications include retail, hospitality spaces, fitness centers, convention centers, exhibit spaces, conference rooms, atriums, museums and transit centers.
Control 68HP features a 209mm (8-inch) low-frequency driver with a Kevlar-reinforced cone and a 50mm (2-inch) voice coil with fiberglass voice coil former for superior power performance and long-term reliability. A coaxially-mounted 25mm (1-inch) compression driver features a titanium dome with damped resonance and a Kapton voice coil former for enhanced long-term fidelity and output capability.
A 68-watt multi-tap transformer is included for use on 70V/100V distributed loudspeaker lines and is switchable for 8-ohm direct operation. And, its 110° constant-directivity dispersion pattern allows for the use of fewer speakers, reducing the cost of the installed system without sacrificing performance.
Installation is fast and easy with Control 68HP's secure mounting system. Two complete hanging cable systems are included, providing both main and safety suspension cables. Suspension height is infinitely adjustable using the included 4.5-meter high-tensile galvanized steel wire rope with spring clips and UL listed cable fasteners.

Click Here for Printer Friendly Version

JBL Control 68HP 8-Inch Coaxial Pendant Speaker Features

- 200 mm (8-inch) long-throw driver with polypropylene cone, long excursion TPV surround, and large-diameter 50 mm (2-inch) voice coil on glass fiber former
- 150W Pink Noise Power Handling (300W program) in direct 8Ω setting, plus built-in 80W subwoofer-band 70V/100V multi-tap transformer
- Tough polyethylene enclosure resists abuse from lawn care equipment and the elements
- IP56-rated to withstand the elements, with a tough polyethylene enclosure and a fully-sealed center wiring chamber

JBL Control 68HP 8-Inch Coaxial Pendant Speaker Specifications

- Frequency Range (-10 DB): 52 Hz - 17 kHz
- Frequency Response (±3 DB): 72 HZ - 16 KHZ
- Power Capacity:
  - 150 Watts Continuous Pink Noise Power (600 Watts peak, 100 hrs)
  - 250 Watts Continuous Pink Noise Power (1000 Watts peak, 2 hrs)
  - 500 Watts Continuous Program Power (2 hr)
- Nominal Sensitivity: 90 dB
- Nominal Coverage Angle: 110° conical
- Directivity (Q): 7.8
- Directivity Index (DI): 8.9 dB
- Maximum Input Voltage: 41.4 V RMS (2 hrs), 82.8 V peak
- Rated Maximum SPL @ 1m: 114 dB continuous pink noise, 120 dB peak
- Rated Impedance: 8 ohms
- Transformer Taps:
  - 70V: 68W, 34W, 17W, & 8.5W
  - 100V: 68W, 34W, 17W
- Transformer Insertion Loss: 0.5 dB @ 8.5W, 0.5 dB @ 17W, 0.6 dB @ 34W, 0.7 dB @ 68W
- Recommended Protective High-Pass: 60 Hz high-pass (24 dB/oct) for 8 ohm operation and for all 70V/100V tap settings
- Drivers:
  - LF: 209 mm (8 in) Kevlar(tm) reinforced cone, 50 mm (2 in) CCAW voice coil on fiberglass voice coil former
  - HF: 25 mm (1.0 in) compression driver, titanium dome, ferrite magnet assembly, Kapton(tm) voice coil former
- Enclosure Material: High impact polystyrene
- Grille: Zinc-plated steel grille with powder-coat finish, foam backing (removable for painting)
- Environmental: Exceeds Mil Spec 810 for humidity, salt spray, temperature & UV. IP44 capability per IEC 529 – splashproof rating.
- Termination: Two removable locking euro-block 2-pin connectors with screwdown terminals for bare wire. Connectors paralleled for input and loop-thru. Max. wire 12 AWG (2.5 mm2). Rubber terminal covers included.
- Suspension: Two identical suspension systems (one as main suspension cable and the other as safety cable), each consisting of 4.5 m (15 ft) long 2 mm (0.077 in) hightensile galvanized-steel wire rope suspension cable with spring-clips for clipping onto the loudspeaker bracket and Gripple brand adjustable-height cable fasteners for infinitely adjustable height. Cables have SWL rating of 45 kg (99 lb).
- Product Compliance: Speaker listed per UL1480A Commercial and Professional Use, (UEAY/7), CSA C22.2 No. 205. Transformer registered per UL 1876. Compliant with IEC62368-1, CE, LVD, RoHS. In accordance with IEC60849/EN60849. Suspension system and Gripple-brand cable fastener listed per UL1598 and UL2239, TUV, and CSA Class 3426-01 & Class 3426-81

Physical:
- Dimensions (W x H x D): 333 x 344 x 333 mm (13.1 x 13.6 x 13.1 inches)
- Weight: 7.5 kg (16.5 lbs)

Further Product Information Below

JBL Control 68HP Data Sheet (PDF)

JBL Control 60 Series Installation Instructions (PDF)

JBL Control 68HP 8-Inch Coaxial Pendant Speaker Supplied With

- 2x Suspension cable systems (see "Suspension", above)
- 2x 2-pin removable locking euro-block connectors
- 2x Rubber covers for euro-block connectors
