JBL Control 12C/T-BK 3-Inch Compact Ceiling Speaker (Pair), 40W @ 8 Ohms or 70V/100V Line - Black

JBL Control 12C/T-BK 3-Inch Compact Ceiling Speaker Features

- 76 mm (3-inch) full-range driver
- Blind-mount backcan for quick and easy install
- Combined 70V/100V and low impedance direct operation
  - 20 Watts at 8Ω nominal setting
  - 15W multi-tap at 70V/100V
- 68 Hz - 17 kHz bandwidth with wide 130° coverage

JBL Control 12C/T-BK 3-Inch Compact Ceiling Speaker Specifications

- Frequency Range (-10dB): 68 Hz - 17 kHz
- Power Rating: IEC System Long-Term Ratings (low-Z direct):
  - 40 Watts Continuous Program Power
  - 20 Watts Continuous Pink Noise (80W peak), 100 hr
- Transformer Taps: 15 W, 7.5 W, 3.8 W @ 70V and 100V (& 1.9 W @ 70V only)
- Frequency Response (±3 dB): 95 Hz - 15 kHz
- Sensitivity: 84 dB (1kHz - 16 kHz)
- Coverage Angle: 130° conical
- Directivity Factor (Q): 9.8
- Directivity Index (DI): 7.4 dB
- Maximum SPL (1m): 97 dB (low-impedance, 103 dB peak)
- 96 dB (top 70V/100V tap)
- Impedance: 8 ohms (in direct/bypass 8Ω setting)
- Drivers: 76 mm (3 inch) with polypropylene cone, butyl rubber surround, Kapton voice coil former, high temperature voice coil, aluminum coupling ring for low distortion and HF extension
- Input Connectors: Removable locking 4-pin connector with screw-down terminals. Max wire size 12 AWG (2.5 mm2)
- Connector Wiring: Pin 1 = + In; Pin 2 = - In; Pin 3 = + Loop Thru; Pin 4 = - Loop Thru
- Strain Reliefs: Strain relief for two cables or two flex conduits via coupled clamping mechanism
- Materials: ABS baffle with UL94-V0 and UL94-5VB flame class fire rating. Zinc-plated steel backcan
- Safety Agency: UL1480, UL2043, NFPA90 & NFPA70; S7232/UL Listed, Suitable for use in air handling spaces, Signaling Speaker; Transformer UL registered per UL1876; ROHS, C-tick N108, CE compliant; Baffle meets UL94-V0 and UL94-5VB flammability rating; In accordance with IEC60849/EN60849 systems
- Dimensions: 196 mm diameter x 138 mm depth from back of baffle (7.7 in diameter x 5.4 in depth)
- Ceiling Cutout Size: 170 mm (6.7-inch) diameter (cardboard cutout template included)
- Ceiling Thickness Range: Up to 35 mm (1.4-inch) with stock dog-ears. MTC-TCD thickceiling dog-ears available for up to 55 mm (2.2-inch) ceiling thicknesses.
- Safety Seismic Attachment: One point, top surface
- Net Weight: 1.6 kg (3.5 lbs, one speaker)
- Shipping Weight: 6.7 kg (14.7 lbs, pair in master carton)
- Optional Accessories: MTC-24NC new construction bracket MTC-24MR mud-ring construction bracket MTC-TCD thick-ceiling dog-ears for ceiling thicknesses up to 55 mm (2.2 in, ordering one set = 24 dog-ears for 8 speakers) MTC-48TR tile rail for 1200 mm (4 ft) tile spans
- Color: Black or Black
- Backcan: formed steel (included "blind-mount-inch)
- Baffle/Rim: ABS baffle with UL94-V0 and UL94-5VB flame class fire rating.
- Plenum Usage: Yes, backcan included

Further Product Information Below

JBL Control 12C/T-BK Data Sheet (PDF)

JBL 10 Series Manual (PDF)

JBL Control 12C/T-BK 3-Inch Compact Ceiling Speaker Supplied With

- 2x JBL Control 12C/T-BK ceiling speakers
- C-ring support backing plate
- 2 tile support rails (fits both 2 ft and 600 mm tiles)
- Cutout template
- Paint shield
- Removable locking wiring connector - Euroblock
