Infinity TCYC-7 300W RGBCALDB LED Cyclorama Flood

Infinity TCYC-7 300W RGBCALDB LED Cyclorama Flood Features

- 300 W lumiled 7 colour LED engine using custom designed array
- CRI > 96 consistently on full CCT range
- LED colour linearity and temperature drift compensation
- Optics Colour Shift compensation
- Colour wheel with 64 spectrum matching Filter gels

Infinity TCYC-7 300W RGBCALDB LED Cyclorama Flood Specifications

Source:
- Light Source Type: LED
- Light Source Quantity: 7
- Light Source Power: 300 W
- LED Colour Type: RGBCALDB
- Life Expectancy: 30000 h
- Refresh Rate (Max.): 1 kHz
- Luminous Flux (Total): 6000 lm
- CRI: 96
- Minimum CCT: 2000 K
- Maximum CCT: 8000 K

Optical:
- Beam Angle (Horizontal): 75 °
- Beam Angle (Vertical): 140 °

Control and Programming:
- Control Mode: DMX, Manual
- DMX Channels: 1, 6, 7, 11, 21
- Protocols: DMX, RDM
- Display: LCD
- Fan mode: Yes
- Dim Curve: Linear, Square, I-Square, S-Curve
- Dimmer Resolution: 16 bit

Dynamic Effects:
- Dimmer: 0-100 %
- Strobe: 0-20 Hz

Electrical Specifications and Connections:
- Power Supply: 100-240 V AC 50/60 Hz
- Power Consumption: 310 W
- Power Connector In: PowerCON Blue
- Power Connector Out: PowerCON Grey
- DMX Connector: XLR 5P In/Out
- DMX Connector In: XLR 5P
- DMX Connector Out: XLR 5P

Mechanical Specifications:
- IP Rating: IP20 (indoor use only)
- Housing: Aluminium
- Colour: Black
- Dimensions (W x H x D): 566 x 285 x 195 mm
- Weight: 11.2 kg

Rigging:
- Mounting Options: Bracket

Product Properties:
- Cooling: Axial fan

Thermal Specifications:
- Maximum Ambient Temperature: 40 °C
- Maximum Surface Temperature: 55 °C

Further Product Information Below

Infinity TCTC-7 Manual (PDF)

Infinity TCTC-7 Photometrics (PDF)
