FBT MDS 1120 Integrated Amplifier with CD, USB, SD Card and Tuner, 120W @ 4 Ohms or 25V / 70V / 100V Line

FBT MDS 1120 Integrated Amplifier with USB, SD Card and Tuner Features

- MP3 file player using USB, SD or MMC card
- FM digital tuner
- 3x MIC/LINE inputs with operating mode selector switches
- Input 1 with VOX priority
- 1x Auxiliary input for sound sources (CD)
- XLR sockets for connection of microphones and/or MBT6400S microphone stations
- Terminal strip for loudspeakers output (25-70-100V / 4Ohm)
- Terminal strip for external 24Vdc power supply
- Terminal strip for microphone priority
- Possibility to connect an external equaliser and / or booster
- Provision for mounting in a standard 19-inch rack space
- Selectable mains power (230/120Vac)

FBT MDS 1120 Integrated Amplifier with USB, SD Card and Tuner Specifications

- Rated power output: 120 W
- Constant voltage outputs: 25, 70 or 100 V
- Low impedance outputs: 4 Ω

Tones control:
- Bass: ±12 dB (100 Hz)
- Treble: ±11 dB (10 kHz)

Microphone/Line Inputs:
- Input sensitivity/impedance:
  - Mic: 3 mV / 1.5 kΩ
  - Line: 250 mV / 100 kΩ
- S/N Ratio:
  - Mic: 70 dB
  - Line: 76 dB
- Frequency response: 35 - 16,000 Hz
- Vocal Activation Threshold: 0.9 mV
- Phantom Supply: 18V / 2.2 kΩ

Auxiliary Input:
- Sensitivity/impedance: 400 mV / 22 kΩ
- S/N Ratio: 80 dB
- S/N Ratio ('A' weighted): 82 dB
- Frequency response: 30 - 18,000 Hz
- Vocal and Precedence attenuation: -60 dB

PWR input:
- Input sensitivity/impedance: 1 V / 22 kΩ
- S/N Ratio: 93 dB
- S/N Ratio ('A' weighted): 100 dBA
- Frequency response: 30 - 18,000 Hz

- Line Output: 1 V / 200 Ω
- Pre Output: 1 V

Electrical:
- 230 V Mains power supply (±10% 50/60 Hz): 300 W
- External DC power supply: 24 V / 10 A

Physical:
- Dimensions (W x H x D): 430 x 88 x 270 mm
- Weight: 8.3 kg
