FBT CSL 520 TIC 5-Inch Coaxial Ceiling Speaker, 20W @ 8 Ohms or 70V / 100V Line

FBT CSL 520 TIC 5-Inch Coaxial Ceiling Speaker Features

- Metal back cover
- Coaxial loudspeaker with 5-inch woofer and ½-inch tweeter
- 88dB±3dB sensitivity @1W/1m
- Nominal power 2,5/5/10/20W/8ohm with 100V/70V line transformer
- Building-in hole 170mm

FBT CSL 520 TIC 5-Inch Coaxial Ceiling Speaker Specifications

- Rated Power: 20 W
- Nominal Impedance: 8 Ω
- Transformer Taps: 2.5 W, 5 W, 10 W, 20 W
- Sensitivity ( @1W / 1m ): 88 dB
- Frequency Response: 100 Hz - 20 KHz -6 dB
- Drivers:
  - HF: ½-inch Mylar tweeter
  - LF: 5-Inch Polypropylene woofer

Physical:
- Colour: White (RAL 9016)
- Cutout: 170 mmØ
- Dimensions: 203 mmØ x 145 mm
- Weight: 1.8 kg

Further Product Information Below

FBT CSL 520 TIC Data Sheet (PDF)
