Cloud MA80FT Mono Mixer Amplifier, 80W @ 4 Ohms or 25V / 70V / 100V Line

The Cloud MA80FT Mono Mixer Amplifier is a Mini Amplifier providing 80W Mono Output at either 4Ω (low impedance) or 70/100v line which is switchable via rear Dip switches. It is fitted with a paging Microphone input with access contacts, a useful 70/100v line input a futher two line inputs and Facility Port input allowing connection of the LM-2 Input Module Wall Plates and the BT-1F Bluetooth Audio Wireless Input Module.
Designed for integration into commercial audio installations and AV systems where de-centralisation of the system component is an advantage. It is intended as an "install and forget" component and is small enough to be fitted into a wall or ceiling void, or directly adjacent to a projector, flat screen or loudspeaker.
The Vloud MA80FT is powered internally via 100-240V SMPS.

Click Here for Printer Friendly Version

Cloud MA80FT Mono Mixer Amplifier, 80W @ 4 Ohms or 25V / 70V / 100V Line Features

- 1 x 80W Output
- High Impedance Line Output 100/70/25V
- Low Impendance Line Output 4Ohm Min Load
- APD - Auto Wake & Hibernation
- Mic Input with EQ and Input Gain
- Music EQ Plus Optional EQ Card
- Paging Mic Access Contacts (SW/VOX)
- Facility Port Input
- Aux Output
- Dynamic Clip, Thermal & Short Protection
- Integrated Universal Power Supply

Cloud MA80FT Mono Mixer Amplifier, 80W @ 4 Ohms or 25V / 70V / 100V Line Specifications

Line Inputs
- Frequency Response: ±1 dB, 20 Hz to 20 kHz
- THD+N: <0.05% (1 kHz, full power, 22 kHz bandwidth)
- Sensitivity: -12 dBu (195 mV) to +8 dBu (2.0 V)
- Input Gain Control: 20 dB range
- Input Impedance: 47 kΩ Headroom 16 dB
- Noise: <-95 dBMusic
- Equalisation:
  - LF: ±10 dB @ 50 Hz
  - HF: ±10 dB @ 10 kHz

Microphone Input
- Frequency Response: -3 dB @ 100 Hz (filter) to 20 kHz ±1 dB
- THD+N: <0.05% (1 kHz, full power, 22 kHz bandwidth)
- Gain: 10 dB to 50 dB
- Input Impedance: 2.7 kΩ (balanced)
- Headroom: 16 dB
- Noise: EIN -127 dB (22 kHz bandwidth, Rs = 150 Ω)
- Phantom Power: +12 V (internal jumper)
- Mic Equalisation:
  - LF: ±12 dB @ 100 Hz
  - HF: ±12 dB @ 5 kHz

General
- Frequency Response:
  - Mic i/p: -3 dB @ 100 Hz (fixed filter) to 20 kHz ±1 dB
  - Line 2 i/p: ±1 dB 20 Hz to 20 kHz
- Input Gain Control: 10 dB to 20 dB
- Noise: <88 dB rms (22 kHz bandwidth)Facility Input
- Frequency Response: ±1 dB 20 Hz to 20 kHz
- Sensitivity: 0.775 V (0 dBu)
- Input Impedance: 10 kΩ (balanced)
- Headroom: 18 dB
- Noise Gate: -60 dBu

Further Product Information Below

Cloud MA80FTEK Manual (PDF)

Cloud MA80FTEK Data Sheet (PDF)
