Citronic QP2320 Quad Power Amplifier, 4x 450W @ 4 Ohms

Name: Citronic QP2320 Quad Power Amplifier, 4x 450W @ 4 Ohms
Brand: Citronic
SKU: 5015972114698
Price: 394.14 GBP
Availability: InStock

Price Each £328.45 (£394.14 Including VAT at 20%)

REF: JP67172

Quantity:

Citronic QP2320 Power Amplifier, 4x 300W @ 4 Ohms

The Citronic QP2320 Power Amplifier, 4x 300W @ 4 Ohms is a range of quad power amplifiers with 4 fully independent channels and individual volume controls. Fully balanced line inputs and parallel outputs allow signal daisy-chaining to further amplifiers. Designed as a cost effective and efficient solution for multi speaker installations where sound quality is paramount.

Click Here for Printer Friendly Version

Citronic QP2320 Power Amplifier, 4x 300W @ 4 Ohms Features

- Fully balanced signal path
- Stable down to 2 Ohms
- 2U rack-mountable

Citronic QP2320 Power Amplifier, 4x 300W @ 4 Ohms Specifications

- Power Supply: 230Vac, 50Hz (IEC)
- Input (Line): 4x XLRF balanced
- Output (Line): 4x XLRM (Parallel from inputs)
- Input Impedance: 20 kΩ
- Frequency Response: 5Hz - 50kHz
- THD: 0.05%
- Slew Rate: 40V/usec
- Signal to Noise Ratio: 103dB
- Controls: 4x channel gain
- Speaker Outputs: 4x SPK connectors
- Circuit Protection: Short-circuit, DC, overload, soft-start
- Dimensions: 483 x 439 x 88 mm
- Output Power (RMS):
  - 4x 580W @ 2 Ω
  - 4x 450W @ 4 Ω
  - 4x 300W @ 8 Ω

Further Product Information Below

Citronic QP2320 Manual (PDF)
