Chauvet Pro Rogue R3 Beam 300W Moving Head

Name: Chauvet Pro Rogue R3 Beam 300W Moving Head
Brand: Chauvet Pro
Price: 2289.83 GBP
Availability: InStock

Buy 4+ units for £7144.26 Inc VAT. To Do So, Click Here to Register.

Price Each £1,908.19 (£2,289.83 Including VAT at 20%)

REF: JP104972

Quantity:

Chauvet Pro Rogue R3 Beam Moving Head

The Chauvet Pro Rogue R3 Beam is the light cannon of the Rogue series, outputting over 208,000 lux at 15 meters from its 300 W Ushio NSL lamp. This fully-featured beam can be focused down to 0.8° degrees for extremely focused aerial effects alongside motorized frost and focus options. A color wheel equipped with 14 colors complimented by a gobo wheel with 17 gobos give you a wealth of dynamic effects, and both wheels are fully scrollable at variable speeds. Additionally, the unit features individually overlapping 8 and 24-facet prisms for an endless supply of creative beam looks. The unit is equipped with RDM and DMX protocols and features multiple control personalities.

Click Here for Printer Friendly Version

Chauvet Pro Rogue R3 Beam Features

- Fully featured, high powered beam fixture with a single color wheel, single static gobo wheel, layerable prisms, and 300 W Ushio NSL lamp rated at 8,000 hours life
- Fast and precise movement of pan and tilt functions
- Individually controllable and layerable 8- and 24-facet prisms
- Frost for even light distribution
- Tight 0.8° beam for extremely focused areal effects
- RDM enabled for remote addressing and troubleshooting
- 17 static gobos for massive visual impact

Chauvet Pro Rogue R3 Beam Specifications

Optical:
- Light Source: 300W NSL Ushio lamp, 8000 K (color temp), 8,000 hours life expectancy
- Color Temperature (at full): 7657 K
- CRI: 80.8
- Front Lens Diameter: 153 mm
- Beam Angle: 0.8°
- Field Angle: 1.6°
- Cutoff Angle: 2°
- Lumens - Output: 30,878
- Illuminance (total): 208,006 lux @ 15 m

Dynamic Effects:
- Pan and Tilt: 540°/270°
- Pan and Tilt Ranges: 180°, 360°, 540° pan/90°, 180°, 270° tilt
- Colors: 14 + white, split colors, continuous scroll at variable speeds
- Gobos : 17 + open (17 metal), continuous scroll at variable speeds
- Dimmer: Motorized
- Shutter/Strobe: Motorized
- Focus: Motorized
- Frost: Motorized
- Prism: 8 facets, motorized, rotating
- Prism: 24 facets, motorized, rotating
- Strobe Rate: 0 to 15 Hz
- Move in Black: Yes

Construction / Physical:
- Dimensions: 12.79 x 8.66 x 21.65 in (325 x 220 x 550 mm)
- Weight: 34.4 lb (15.6kg)
- Exterior Color: Black
- Housing Material: High-impact flame-retardant polymer

Connections:
- Power Connection: Edison (Local) plug to Neutrik
- Power Input: Neutrik powerCON
- Power Output: Neutrik powerCON
- Data Connectors: 3- and 5-pin XLR
- Cable Length (power): 5 ft (1.5 m)

Control:
- Control Protocol: DMX, RDM
- DMX Channels: 16 or 19
- Modes/Personalities: 2 personalities (16, 19)

Electrical:
- Input Voltage: 100 to 240 VAC, 50/60 Hz (auto-ranging)
- Power and Current: 422 W, 4.20 A @ 100 V, 60 Hz
- Power and Current: 418 W, 3.55 A @ 120 V, 60 Hz
- Power and Current: 411 W, 1.98 A @ 208 V, 60 Hz
- Power and Current: 411 W, 1.78 A @ 230 V, 50 Hz
- Power and Current: 406 W, 1.68 A @ 240 V, 50 Hz

Certifications / Qualifications:
- CE, MET
- IP Rating: IP20, dry location
- Temperature (Ambient): -4 °F to 113 °F (-20 °C to 45 °C)

Further Product Information Below

Chauvet Pro Rogue R3 Beam Manual (PDF)

Chauvet Pro Rogue R3 Beam Quick Reference Guide (PDF)

Chauvet Pro Rogue R3 Beam Photometrics (PDF)

Chauvet Pro Rogue R3 Beam Supplied With

- Rogue R3 Beam
- Neutrik powerCON power cord
- 2 Omega brackets with mounting hardware

Chauvet Pro Rogue R3 Beam Accessories

- Professional Clamps: CTC-50HC, CTC-50HCN
- Safety Cable: SC-07
- DMX cables
- Flight Case: #CP2CASER2XR3SPOT
- UPLOAD 08 software uploader
