Chauvet Pro Ovation Rêve E-3 IP Full-Spectrum LED Profile, IP65 - Light Engine Only - NO LENS TUBE

Chauvet Pro Ovation Rêve E-3 IP Full-Spectrum LED Profile Features

- Full-spectrum, high-power LED ERS-style lighting fixture for theatre, film, and production
- Fully IP65 rated for seasonal use indoors or out
- Linear color temperature presets from 2800 K to 8000 K with high CRI and CQS
- Virtual color wheel with color matched to popular gel colors
- ± Green adjustment and emulated red-shift via DMX or on-board control
- RDM (Remote Device Management) for added flexibility
- Adjustable PWM (Pulse Width Modulation) to avoid flickering on camera
- Virtually silent operation for use in studio, film, and theatre applications
- Ultra-smooth 16-bit dimming curves and speeds to complement any lighting scheme.
- Innovative adjustable yoke for mounting in low clearance areas
- Direct power/data connection and control options for the Ovation GR-1 gobo rotator
- USB port for fixture software updates

Chauvet Pro Ovation Rêve E-3 IP Full-Spectrum LED Profile Specifications

Optical:
- Light Source: 91 LEDs (12 red, 19 green, 3 blue, 9 royal blue, 24 amber, 24 mint) 3.5 to 10 W, (2.4 A), 50,000 hours life expectancy
- Color Temperature (range): 2800 to 8000 K
- Color Temperature (at full): 6,428 K
- CRI: 93.5
- Beam Angle:
  - 5° lens: 6.7°
  - 10° lens: 11.1°
  - 14° lens: 14.2°
  - 19° lens: 17.6°
  - 26° lens: 26°
  - 36° lens: 32.8°
  - 50° lens: 50°
  - 15°-30° lens)(Narrow): 14.3°
  - 15°-30° lens)(Wide): 23.8°
  - 25°-50° lens)(Narrow): 24.7°
  - 25°-50° lens)(Wide): 41.1°
- Field Angle:
  - 5° lens: 7.9°
  - 10° lens: 12.8°
  - 14° lens: 16.9°
  - 19° lens: 20.8°
  - 26° lens: 28.2°
  - 36° lens: 37°
  - 50° lens: 54.2°
  - 15°-30° lens)(Narrow): 17.3°
  - 15°-30° lens)(Wide): 33.2°
  - 25°-50° lens)(Narrow): 27.3°
  - 25°-50° lens)(Wide): 44.7°
- Lumens:
  - 5° lens: 8,335
  - 10° lens: 11,092
  - 14° lens: 10,700
  - 19° lens: 10,185
  - 26° lens: 12,178
  - 36° lens: 11,888
  - 50° lens: 11,274
  - 15°-30° lens)(Narrow): 9,166
  - 15°-30° lens)(Wide): 11,395
  - 25°-50° lens)(Narrow): 11,810
  - 25°-50° lens)(Wide): 14,328
- Illuminance:
  - 5° lens: 28,740 lux @ 5 m
  - 10° lens: 15,108 lux @ 5 m
  - 14° lens: 8,823 lux @ 5 m
  - 19° lens: 5,377 lux @ 5 m
  - 26° lens: 3,300 lux @ 5 m
  - 36° lens: 1,977 lux @ 5 m
  - 50° lens: 864 lux @ 5 m
  - 15°-30° lens)(Narrow): 7,731 lux @ 5 m
  - 15°-30° lens)(Wide): 2,484 lux @ 5 m
  - 25°-50° lens)(Narrow): 3,174 lux @ 5 m
  - 25°-50° lens)(Wide): 1,502 lux @ 5 m
- Selectable PWM: 600 Hz, 1,200 Hz, 2,000 Hz, 4,000 Hz, 6,000 Hz, 25,000 Hz

Dynamic Effects:
- Dimmer: Electronic
- Shutter/Strobe: Electronic
- Focus: Manual
- Strobe Rate: 0 to 28.6 Hz
- Standalone Color Mixing: Yes
- Color Temperature Presets: Yes
- Dim Modes: 4
- Dim Curves: 4
- Built-in Automated Programs: Yes

Connections:
- Power Connection: Edison (Local) plug to PowerCON IP65
- Power Input: PowerCON IP65
- Power Output: PowerCON IP65
- Data Connectors: 5-pin XLR
- Cable Length (power): 5 ft (1.5 m)
- Software Connection: Type-C USB

Control:
- Control Protocol: DMX, RDM
- DMX Channels: 1, 5, 6, 8, 12, 14ch1, 14ch2, 18 or HSV
- Modes/Personalities: 9 personalities (1, 5, 6, 8, 12, 14ch1, 14ch2, 18, HSV)

Electrical:
- Power Linking: 7 units @ 230 V
- Input Voltage: 100 to 240 VAC, 50/60 Hz (auto-ranging)
- Power and Current: 342 W, 1.555 A @ 230 V, 50 Hz

Certification / Qualification:
- CE, MET, FCC, UKCA
- IP Rating: IP65, temporary outdoor/wet use, with pressure equalizing M12 GORE valve
- Temperature (Ambient): -4 °F to 113 °F (-20 °C to 45 °C)

Physical:
- Exterior Color: Black
- Dimensions:
  - Fixture only, yoke up: 529.3 x 323 x 501.7 mm (20.83 x 12.71 x 19.75 in)
  - 5° lens extended, yoke up: 1073.15 x 368.3 x 501.7 mm (42.25 x 14.5 x 19.75 in)
  - 10° lens extended, yoke up: 850.9 x 323 x 501.7 mm (33.5 x 12.71 x 19.75 in)
  - 14° lens extended, yoke up: 768.35 x 323 x 501.7 mm (30.25 x 12.71 x 19.75 in)
  - 19°, 26°, 36° or 50° lens extended, yoke up: 698.5 x 323 x 501.7 mm (27.5 x 12.71 x 19.75 in)
  - 15°-30° lens, yoke up: 857.25 x 323 x 501.7 mm (33.75 x 12.71 x 19.75 in)
  - 25°-50° lens, yoke up: 673.1 x 323 x 501.7 mm x 26.5 x 12.71 x 19.75 in)
- Weight:
  - Fixture Only: 9.34 kg (20.6 lbs)
  - 5° lens: 11.43 kg (25.2 lbs)
  - 10° lens: 10.79 kg (23.8 lbs)
  - 14° lens: 11.79 kg (26 lbs)
  - 26° lens: 11.06 kg (24.4 lbs)
  - 15°-30° lens: 13.69 kg (30.2 lbs)
  - 25°-50° lens: 12.15 kg (26.8 lbs)

Further Product Information Below

Chauvet Pro Ovation Rêve E-3 IP Manual (PDF)

Chauvet Pro Ovation Rêve E-3 IP Data Sheet (PDF)

Chauvet Pro Ovation Rêve E-3 IP Quick Reference Guide (PDF)

Chauvet Pro Ovation Rêve E-3 IP Full-Spectrum LED Profile Light With

- Chauvet Ovation Rêve E-3 IP
- PowerCON power cable
- Ovation Metal Gobo Holder
- Soft Focus Filter

Please Note: This listing includes the Light Engine only. The Lens Tube and accessories are sold separately.
