Chauvet Pro onAir Flex Drive 2 DMX/24V Driver for onAir Panels

Name: Chauvet Pro onAir Flex Drive 2 DMX/24V Driver for onAir Panels
Brand: Chauvet PRO
Price: 469.31 GBP
Availability: InStock

List Price Displayed - Need a better Price Click Here to Register for a login or give us a call

Price Each £391.09 (£469.31 Including VAT at 20%)

REF: JP105576

Quantity:

Chauvet Pro onAir Flex Drive 2 DMX/24V Driver for onAir Panels

The Chauvet Pro onAir Flex Drive 2 DMX/24V Driver for onAir Panels is an LED Driver ideal for TV studios seeking simple and impactful on-camera looks with integrated power supply and driver for a one-box modular solution. onAir Flex Drive 2 features 24v to allow longer run lengths for set pieces and light boxes, and 8 channels of output for complete flexibility with a choice of tapes and lengths. It also features adjustable PWM, making it ideal for broadcast compatibility. With two outputs, onAir Flex Drive 2 supports RGBW or generic 4-channel control for up to 350W of total power and assisted convection cooling perfect for studio environments. To ease installation, onAir Flex Drive 2 also features DMX 5pin and Phoenix connector for installation support.

Click Here for Printer Friendly Version

Chauvet Pro onAir Flex Drive 2 DMX/24V Driver for onAir Panels Features

- TV focused 24 VDC constant voltage LED Driver with integrated power supply
- Adjustable PWM makes this product ideal for broadcast compatibility
- Two outputs support RGBW or generic 4-channel control for up to 350W of total power
- Assisted convection cooling utilizes a quiet fan for studio environments
- Built in overcurrent and short circuit protection with indicator LEDs
- RDM supported for remote device management
- Scalable rack mount system, two per 1U space
- DMX 5pin and Phoenix connector for installation support

Chauvet Pro onAir Flex Drive 2 DMX/24V Driver for onAir Panels Specifications

Dynamic Effects:
- Standalone Colour Mixing: Yes
- Built-in Automated Programs: Yes

Connections:
- Power Connection: Edison (Local) plug to Neutrik powerCON TRUE1 Compatible
- Power Input: PowerCON (powerCON Compatible)
- Power Output: PowerCON (powerCON Compatible)
- Device Outputs (5-pin Phoenix Connector): 2
- Physical Linking Per Port: 2 RGBW Tape
- Data Connectors: 5-pin XLR, 3 Pin Phoenix Connector
- Cable Length (power): 5 ft (1.5 m)
- Total Max Cable Extension Length Per Port: 100 ft (30.48m) 16 AWG

Control:
- Control Protocol: DMX
- DMX Channels: 8 or 10
- Modes/Personalities: RGBW, RGBW+D
- Total Output Power:
- Per Port: 200 W
- Total: 350 W

Electrical:
- Input Voltage: 100 to 240 VAC, 50/60 Hz (auto-ranging)
- Power Linking: 2 units @ 120 V; 5 units @ 208 V; 5 units @ 230 V;
- Power and Current: 400 W, 1.74 A @ 230 V, 50 Hz

Certification / Qualification:
- CE
- IP Rating: IP20, dry location
- Temperature (Ambient): -4 °F to 113 °F (-20 °C to 45 °C)

Physical:
- Dimensions: 5.4 x 4.3 x 0.8 in (137 x 109 x 20 mm)
- Weight: 5.4 lb (2.44 kg)
- Exterior Colour: Black
- Housing Material: Steel
- Rackmount: 1U

Further Product Information Below

Chauvet PRO onAir Flex Drive 2 Data Sheet (PDF)

Chauvet PRO onAir Flex Drive 2 Quick Reference Guide (PDF)

Chauvet PRO onAir Flex Drive 2 Technical Drawing (PDF)

Chauvet Pro onAir Flex Drive 2 DMX/24V Driver for onAir Panels Compatibility

- Chauvet Pro onAir Panel Min IP
- Chauvet Pro onAir Panel 1 IP
- Chauvet Pro onAir Panel 2 IP

Chauvet Pro onAir Flex Drive 2 DMX/24V Driver for onAir Panels Supplied With

- onAir Flex Drive 2
- Neutrik powerCON TRUE1 power cord
