ChamSys MagicQ Compact Connect USB Lighting Control Interface

ChamSys MagicQ Compact Connect USB Lighting Control Interface Features

- A lightweight USB control surface
- Connects to your PC or Mac to control lighting, media, and LEDs
- 2 direct DMX512 outputs
- Up to 64 universes of ArtNet and sACN directly from its onboard network port
- 10 playback faders featuring Flash, Go and Select buttons as well as dedicated Grand Master and Crossfader
- Ideal for installation into theatres, schools, clubs, studios and venues

ChamSys MagicQ Compact Connect USB Lighting Control Interface Specifications

Hardware Specifications:
- Direct DMX Outputs: 2
- Fader Playbacks: 10
- Attribute Encoders: 8
- USB Ports: 5 (4 USB-A output, 1 USB-C input)
- Network Ports: 1
- Audio Input: (1 channel, 7 band): Yes
- 10 Scene Input: Yes
- Kensington Security Lock Fixing: Yes
- Working Light Port: Yes
- Power Input, Neutrik powerCON TRUE1 110 to 240 VAC

Software Specifications:
- Universes: 64
- Max Number of DMX Channels: 32768
- Max Number of Fixtures Supported: 32768
- Max Number of Cues: 5000
- Max Number of Cue Stacks: 2000
- Max Number of Groups: 5000
- Max Number of Palettes: 4096
- Number of Media Server Layers Supported: 50 (each different content)
- Supported on Windows (8.1 or higher), macOS (10.13 or higher) and Linux

Physical:
- Dimensions (W x H x D): 522 x 78 x 230 mm
- Weight: 3.65 kg

Further Product Information Below

ChamSys MagicQ Compact Connect Manual (PDF)

ChamSys MagicQ Compact Connect USB Lighting Control Interface Supplied With

- USB A-C Cable: 1
- Dual Colour Desk lights: 1
- Dust Cover: 1
- Neutrik powerCON TRUE1 Power Cable: 1
