Biamp REVAMP2060T 2-Channel Power Amplifier, 2x 60W @ 4 Ohms or 35V / 50V / 70V / 100V Line

Biamp REVAMP2060T 2-Channel Power Amplifier Features

- Professional 2-channel digital power amplifier
- Class-D Amplifier
- 2 x 60 watts output power at 100 volts or at 4 ohms
- Can easily be bridged into a powerful 120 watts at 100 volts or 8 ohms single amplifier
- LED indicator for configuration of the input gain
- Slim 1U design without front control

Biamp REVAMP2060T 2-Channel Power Amplifier Specifications

- Dynamic output power 4 Ω: 2 x 60 watts
- Dynamic output power 8 Ω: 2 x 30 watts
- Dynamic output power bridged 8 Ω: 120 watts
- Output power RMS 100 volts: 2 x 60 watts
- Minimum impedance load per channel: 4 Ω
- Power consumption (max): 175 watts
- Height- rack units (1U=44 mm): 1U
- Power supply technology: Switching mode power supply
- output channels: 2
- Line input unbalanced: 2
- Power amp topology: Class-D
- Cooling system: Convectional
- Applicable low impedance: Yes
- RMS output power 4 Ω: 2 x 60 watts
- RMS output power 8 Ω: 2 x 30 watts
- Output power RMS bridged 8 Ω: 120 watts
- Output power RMS bridged 100 volts: 120 watts
- Minimum impedance load bridged per channel: 8 Ω
- 19" (483 mm wide) rack mounting: Yes
- Power supply: 115 - 230 VAC
- Output voltage tappings: 100 - 70 - 50 - 35 volts - 4 Ω
- Line input balanced: 2
- Channel separation: > 65 db @ 1kHz
- Frequency response (in Hz): 50 - 20 k
- Applicable in 100V: Yes

Physical:
- Dimensions (W x H x D): 483 x 44 x 239 mm
- Weight: 5.7 kg

Data Sheets below

Biamp REVAMP2060T Data Sheet (PDF)

Biamp REVAMP2060T Manual (PDF)
