Biamp MA30 Mixer Amplifier with 2x Microphone, 2x Line Inputs - 30W @ 4 Ohms or 70V / 100V Line

Biamp MA30 Mixer Amplifier Features

- Intuitive user interface
- Prominent, illuminated front volume control
- Compact 9.5-inch housing
- Smart left-to-right 4 level priority and rear panel design
- 1 mic/line input and 2 stereo line, mono summed inputs
- Emergency input, paging mic with chime and a 24VDC override output on rear panel

Biamp MA30 Mixer Amplifier Specifications

- Power supply: 100 - 240 VAC
- Power consumption (max): 60 watts
- Output power RMS 100 volts: 30 watts
- Output power RMS 4 Ω: 30 watts
- Dynamic output power 100 volts: 30 watts
- Minimum impedance load: 4 Ω
- Output power tappings: 70 - 100 volts - 4 Ω
- Zone outputs: 1
- MIC inputs balanced: 2
- Inputs with Phantom power: 1
- Line input unbalanced: 2
- Tone control: Yes
- Priority switch: 2
- VOX mute: Yes
- Chime: Yes
- Emergency input: 1
- Priority output: 1
- Priority levels: 4
- Power amp topology: Class-D
- Frequency response (in Hz): 60 - 20 k
- Cooling system: Convection
- Applicable in 100V: Yes
- Applicable low impedance: Yes

Physical:
- Dimensions (W x H x D): 216 x 89 x 250 mm
- Weight: 2.4 kg

Data Sheets below

Biamp MA30 Data Sheet (PDF)

Biamp MA30 Manual (PDF)
