Allen & Heath ZEDi-10 Compact Hybrid Mixer with USB Interface

Name: Allen & Heath ZEDi-10 Compact Hybrid Mixer with USB Interface
Brand: Allen & Heath
Price: 253.43 GBP
Availability: InStock

Price Each £211.19 (£253.43 Including VAT at 20%)

REF: JP104104

Quantity:

Allen & Heath ZEDi-10 Compact Hybrid Mixer with USB Interface

The Allen & Heath ZEDi-10 Compact Hybrid Mixer with USB Interface combines the robustness and hands-on control of an analogue mixer with a high quality 4 x 4 USB interface, making it a perfect all-round choice for musicians, recording artists and venues. Whether it's bouncing ideas around at home, performing live or recording tracks to share on YouTube and Soundcloud, ZEDi-10 is a versatile companion for every step of the creative journey.
The studio quality, 24-bit / 96kHz, 4x4 USB interface makes it easy to capture stunning multitrack recordings direct from the mixer to a Mac or PC without the need for any extra equipment. Featuring the new GSPre boutique preamp design, developed from the revered GS-R24 studio recording console, the ZED boasts exceptionally low noise and massive headroom, with a signature analogue warmth and depth. Guitarists will be pleased to know that two of ZEDi-10's mono channels feature Guitar DI high impedance inputs, allowing guitars to be plugged straight into the mixer without the hassle and expense of carrying separate DI boxes.

Click Here for Printer Friendly Version

Allen & Heath ZEDi-10 Compact Hybrid Mixer with USB Interface Features

- 4 in, 4 out USB Audio Interface (24-bit/96kHz)
- Cubase LE Software included
- Cubasis LE App included
- 4 Mic / Line Inputs with separate XLR and TRS jack sockets
- 2 Stereo Inputs with TRS jack sockets
- 2 Guitar DI high impedance inputs, eliminating the need for DI boxes
- Lo-cut filter for cleaning up unwanted low frequency noise
- 3 band EQ for easy creative and corrective tonal shaping
- FX out for connecting external effects units
- Aux out for connecting a monitor speaker or in-ear / headphone monitoring
- 60mm smooth travel fader on main mix
- XLR main outputs
- Flexible signal monitoring
- 8 LED signal metering
- 48V Phantom Power for condenser mics
- Robust internal power supply

Allen & Heath ZEDi-10 Compact Hybrid Mixer with USB Interface Specifications

Input
- Mono channel 1-2 (XLR) Input (For Nominal 0dBu) -5dBu to -60dBu (+13dBu maximum)
- Mono channel 3-4 (XLR) Input (For Nominal 0dBu) Pad IN +15dBu to -40dBu (+23dBu maximum)
- Mono channel 1-2 Instrument/Line Input (Jack socket) +14dBu to -40dBu (+17dBu maximum)
- Mono channel 3-4 Line Input (Jack socket) +15dBu to -40dBu (+23dBu maximum)
- Stereo Input (Jack sockets) 0dBu nominal (control = Off to +15dB Gain)

Output
- L/R Outputs (XLR) 0dBu (+18dBu maximum)
- Aux & FX Output (Jack sockets) 0dBu (+18dBu maximum)
- Monitor Output L/R (RCA Phono Sockets) 0dBu (+18dBu maximum)

Frequency Response
- Mic in to Mix L/R Out, 30dB gain 10Hz to 30kHz +0.5/-1dB
- Instrument/Line in to Mix L/R out 0dB gain 10Hz to 30kHz +0.5/-1dB
- Stereo in to Mix L/R out 10Hz to 30kHz +0.5/-1dB

THD+n
- Mic in to Mix L/R Out, 10dB gain 1kHz +10dBu out (22Hz-22kHz Filter) 0.002%
- Mic in to Mix L/R Out, 30dB gain 1kHz (22Hz-22kHz Filter) 0.005%
- Instrument in to Mix L/R out 0dB gain 0dBu 1kHz (22Hz-22kHz Filter) 0.03% 2nd Harmonic
- Stereo in to Mix L/R out 0dB gain +10dBu 1kHz (22Hz-22kHz Filter) 0.0025%

Headroom
- Analogue Headroom from nominal (0Vu) 18dB
- USB in & out headroom from nominal (0Vu) 18dB

Noise
- Mic Pre EIN @ max gain 150R input Z (22Hz-22kHz Filter) -127dBu
- Mix L/R out, L/R fader = 0, Channel Levels min (22Hz-22kHz Filter) -93dBu
- Mix L/R out, L/R faders = 0, Channel Levels 0dB (22Hz-22kHz Filter) -90dBu

USB Audio
- USB Audio In/Out USB 2.0 compliant
- Bit Depth 24 bit
- Sample Rate 44.1, 48, 88.2, 96kHz

Physical & Dimensions
- Height: 96.5mm
- Width: 332.9mm
- Depth: 274.6mm
- Weight: 2.2kg

Further Product Information Below

Allen & Heath ZEDi10/240X Manual (PDF)

Allen & Heath ZEDi10/240X Data Sheet (PDF)

Allen & Heath ZEDi-8 Data Sheet (PDF)
