Allen & Heath QU-32 Digital Mixer

Allen & Heath QU-32 Digital Mixer Features

- 32 Mono Mic/Line Inputs (TRS + XLR)
- Recallable AnaLOGIQTM Preamps
- 3 Stereo Inputs (TRS)
- 24 Mix Outputs (XLR)
- 4 Stereo Groups (switchable to Mix mode)
- Up to 11 Monitor Mixes (4 mono + 7 stereo)
- 2 Stereo Matrix Outs
- 4 FX Engines
- 4 dedicated FX Sends / Returns
- 4 Mute Groups
- 4 DCA Groups
- AES Digital Out
- 32 x 32 USB Audio Interface
- dSNAKE Remote Audio Port
- 33 Motor Faders
- 7 inch Touchscreen
- 10 Soft Keys
- Trim, polarity, HPF, gate, insert, 4-band PEQ, compressor, delay on all Inputs
- Insert, 4-band PEQ, ⅓ octave GEQ, compressor, delay on all Outputs
- Automatic Mic Mixer
- Channel Ducker on all inputs
- ProFactory Mic Presets
- RackFX Library
- Built-in Signal Generator
- RTA with Peak Band indication
- Spectrogram to aid feedback elimination and room acoustics
- Automatic Mic Mixer
- Qu-Drive Direct Multitrack Recording / Playback on USB drives
- DAW MIDI Control
- Qu-Pad iPad App
- Qu-You iPhone / Android personal monitoring app
- Qu-Control customisable iOS app for simple wireless control
- Compatible with ME Personal Mixing System
- High contrast metallic finish controls, matching premium GLD Chrome series

Allen & Heath QU-32 Digital Mixer Specifications

- Channels: 32 Mono, 3 StereoInputs - Mic Preamps: 32 x XLR
- Phantom Power: 32
- Inputs - Line: 32 x ¼ inch
- Inputs - Other: 4 x ¼ inch (2 stereo in), 1 x ⅛ inch TRS (stereo in)
- Inputs - Digital: 1 x Ethernet dSnake, 1 x USB Type A
- Outputs - Digital: 1 x Ethernet dSnake, 1 x XLR AES, 1 x USB Type A
- Outputs - Main:
  - 2 x XLR (left, right)
  - 2 x ¼ inch (2 track out)
  - 2 x ¼ inch (alt out)
- Outputs - Other:
  - 4 x XLR (mono mix outs)
  - 3 x XLR pairs (stereo mix outs)
  - 4 x XLR pairs (stereo group outs)
  - 2 x XLR pairs (stereo matrix outs)
- Busses/Groups: 16-bus
- Data I/O: 1 x Ethernet TCP/IP
- USB: 1 x Type B, 1 x Type A
- Computer Connectivity: USB, 1 x LAN port (connect iOS devices with addition ofwireless network router)
- Headphones: 1 x ¼ inch TRS
- Faders: 32 x 100mm channels, 1 x 100mm master
- EQ Bands: Parametric EQ, 28-band graphic EQ
- Effects: Reverb, delay, chorus, phaser, flanger (4 x stereo FX returns)
- Talkback: 1 x XLR
- DAW Control: MIDI DAW control driver for Mac (HUI, Mackie Control)
- Height: 7.32inch (desktop position)
- Depth: 19.52inch (desktop position)
- Width: 33.42inch
- Weight: 53 lbs
