ADJ Saber Spot 20W RGBL LED Pinspot

Price Each £126.67 (£152.00 Including VAT at 20%)

REF: JP109476

Quantity:

ADJ Saber Spot 20W RGBL LED Pinspot

The ADJ Saber Spot 20W RGBL LED Pinspot expands on the versatility of the modern LED pinspot. Featuring a 20-Watt RGBL (red, blue, green and lime) LEDs source, advanced ACL lens and a tight 5.7-degree beam angle, the Saber Spot RGBL is designed for spotting tables, objects or mirror balls, and creating mid-air beam effects for lightshows.
This fixture is DMX and RDM compliant with 12 DMX channel modes, 63 built-in color macros, 13 built-in color changing programs and has six white color temperature presets ranging from 2700K to 7000K.
A lens kit is supplied with the fixture giving lighting designers the option to change the beam angle to 10 or 45-degrees. Its scissor yoke allows for a variety of hanging options.
The Saber Spot RGBL has a 4-button digital display to navigate through the features and controls, plus indoor power locking In/Thru and 5-pin DMX In/Out pigtails are neatly situated at back of the fixture.

Click Here for More Info.

ADJ Saber Spot 20W RGBL LED Pinspot Features

- DMX and RDM Compliant
- 6 White Color Temperature Settings: 2700K, 3200K, 4000K, 5600K, 6500K & 7000K
- 63 Built-in Color Macros
- 13 Built-in Color Changing Programs
- 4-button Digital Display for easy navigation
- Electronic Dimming 0 – 100%
- Includes a scissor yoke to be hung, or set on the ground

ADJ Saber Spot 20W RGBL LED Pinspot Specifications

Optical:
- Light Source: 20-Watt, RGBL LED
- LED Life Expectancy: 30,000 Hrs
- Beam Angle: 5.7°
- Includes 2 interchangeable frost filter lens (10-degree & 45-degree)
- LED Refresh Rate: 3.6KHz

Connections:
- Power Input: Indoor power locking
- Power Pass through: Indoor power locking
- Control: 5-pin DMX In/Out pigtails
- With Wired Digital Communication Network

Control:
- 12 DMX Channel Modes: 3 HSI/4 RGBL/4 HSI+/5 RGBL/6 sRGBLI/6 RGBL/7 RGBL/8 RGBL/8 16bit/10 HSI/12 sRGBLI/13 RGBL
- RDM Compliant

Electrical:
- Input Voltage: 100-240V 50Hz/60Hz (Auto Sensing)
- Power draw 230V 50Hz: 16.7W, 0.147 Amps
- Power Output Current: 1.2A (14W)
- Power Linking: 57pcs @120V, 95pcs @230V

Certification / Qualification:
- CE
- cETLus Approved (Control # 4010765)
- IP20

Physical:
- Dimensions (W x H x D): 135 x 215 x 170 mm
- Weight: 1.45 kg

Further Product Information Below

ADJ Sabre Spot RGBL Manual (PDF)

ADJ Sabre Spot RGBL Data Sheet (PDF)

ADJ Sabre Spot RGBL DMX Chart (PDF)

ADJ Saber Spot 20W RGBL LED Pinspot Supplied With

- 1x ADJ Saber Spot
- 1x 1.83m Indoor locking power cord
- 2x frost filter lens (10-degree & 45-degree)
- 1x Metal clip ring for frost filter lens
